INSTALLATION INSTRUCTION

LED Step and Wall Lights

WL-LED200

WARNING

IMPORTANT: NEVER attempt any work without shutting o the electricity.

- Read all instructions before installing.

- System is intended for installation by a qualied electrician in accordance with the National Electric Code,

and local regulations. Consult with local inspector to ensure compliance.

- To reduce the risk of re, electrical shock and injuries to persons, turn o power at main switch before installing

or modifying the system.

- Retain instructions for future maintenance reference.

- Not complying with instructions could result in failure of the xtures, and void the warranty.

INSTALLATION:

JUNCTION BOX: 2” x 4” boxes to have minimum inside dimensions of 3”H x 2”W x 2”D in order to accommodate

Note: Actual depth of box to be determined in accordance with the NEC and local ordinances. Indoor or outdoor frame mounted

junction box: Raco 2” x4” (16.5 cu. In) or equivalent recommended Outdoor surface mounted junction box: Red Dot deep

weatherproof box Model S103E or equiv. recommendedMortar or poured concrete installation: Use appropriate junction box

suitable for that particular application

1. Install 2”x4” junction box, and ensure it is water-tight for outdoor use.

2. Secure mounting bracket to J-box using (2) 8-32 J-Box screws (J-box and screws by others) as shown in Fig.1.

3. Insert gasket onto the back of the xture (Fig.2).

Note: For indoor installation, gasket is not required, and can be discarded.

4. Connect the xture wires to the junction box wires as follows: Black xture wire to black (Hot) J-BOX wire, white xture wire to

white (Neutral) J-box wire, and green xture wire to Ground. (See Fig.3)

Note: Multiple xtures (up to 200) can be wired together in parallel: Hot to hot, and neutral to neutral.

5. Place all wiring and connectors back in junction box and install the xture.

Note: For outdoor installation, it is recommended that the installer run a bead of clear, outdoor-rated silicone

(GE RTV-162 or equivalent, provided by others) caulk between gasket or back of xture and mounting surface to

prevent seepage of water into xture.

6. Secure the xture to the surface using two mounting screws and two rubber washers provided. (See Fig.4)

(Note: Fixture, mounting bracket, gasket, mounting screws, and rubber washers provided by WAC.)
