3iE Operating Guide V5 © Warmup plc - 2015

INTRODUCTION

Your thermostat’s default screen is the Home Screen. This screen displays important information such as the time,

current oor and air temperature as well as the target set temperature. From this page you can either

access the “MENU” page (press “menu”) or override the current programmed temperature (press “ ” or “ ”).

When using the 3IE thermostat there are some general rules to keep in mind:

(1) Pressing “ ” allows you to conrm your selection

(2) Pressing “ ” takes you back to a previous page in the

menu sequence

(3) Pressing the “ ” and “ ” buttons allow you to change

the setting which is highlighted

(4) Pressing an illuminated button in this group will

allow you to highlight another setting to edit

(5) Pressing an illuminated button in this group will

allow you to select another option in the menu

(6) When this light is illuminated it indicates that power is

being directed to the heaters

Hint:You will often nd a “help” button on pages with

several options. Press the help button for more

information on the options available.

If you do not press any button on the thermostat for 1 minute, then it will go to standby mode. In standby mode the

screen will be dimmed but the thermostat will continue to function as normal. To exit standby mode press

“wake” ( ).

The button on bottom of the 3IE (button 7) is the power button. You can turn o your thermostat and Warmup

underoor heating system by holding down this button for 3 seconds. You can turn it on again by holding it down for

another 3 seconds.

This button can also be used if you get lost in the menus, press the power button on the bottom once to return to the

home screen.

GETTING STARTED

On initial power up the thermostat will guide you through set up procedure for the following:

Operating Guide:

for the Warmup 3iE Programmable Thermostat

• Language

• Time preference and Settings

• Date preference and settings

• Daylight savings

• Temperature Preference

• Theme

• Brightness

• Standby Brightness

• Heating LED

• Audio Feedback

• Floor type

• Set heating target

• Program schedule

• Set energy monitor (You may

skip this section and complete at a

later date )
