Sida 1/2

The HGST 4U60 Storage Enclosure is a high-density, scalable, and

cost-eective design, using 60 Ultrastar® 3.5-inch drive modules in

a 4U enclosure. It oers 2x2x4-lane SAS 12GB/s performance, high

availability (HA), and hot-swappable components. The design is

targeted towards data centers that need a dense solution with HA

capabilities, while maintaining a low power proile.

DATA SHEET

4U60 Storage Enclosure

Features

•60 integrated Ultrastar® drive modules

— Available with 512e or 4Kn sector size

(by part number)

•Host connectivity 2 x SAS QSFP+ receptacles

per IO Module; optional connectivity cables

are available

— QSFP+ to HD mini SAS cables for host

— QSFP+ to QSFP+ cables for daisy-chaining

•Hot Swappable: two power supplies

(with integrated fans), drive modules, and IO

modules

•Fully compliant with SAS 3.0 speciication for

operation up to 12Gbps

•Cable management arm simpliies

maintenance of hot-swappable CRUs

•SCSI Enclosure Services (SES3)

•Microsoft Certiied for Windows Server 2012

& Windows Server 2012 R2

•5-year limited warranty on Ultrastar HDD

modules, 3-year limited warranty on all

other components

4U 60 S TORAGE ENCLO SURE

4U enclosure

60 Ultrastar drive modules

Available in 3 capacities

: 480TB, 360TB and 240TB

Information & Technical Support

www.hgst.com/4U60

support.hgst.com/4U60

Sales Inquiries

North America: salesna@hgst.com

Europe/Middle East/Africa (EMEA): salesemea@hgst.com

Partners First Program

channelpartners@hgst.com

www.hgst.com/partners

Speciications

Capacity / Physical Size

Capacity

Up to 480TB

Height 174.8 mm (6.88 in.) – 4 Rack Units

Width 424 mm (16.69 in.)

Depth 983 mm (38.7 in.) – including cable management

Weight 480TB

360TB / 240TB

89.81 kg (198 lbs.) – fully conigured with 60 helium HDDs

93.71 kg ( 207.6 lbs) – fully conigured with 60 air HDDs

Power and Cooling: Operating

Two 1650W PSUs, hot-swap and redundant

200240VAC auto-ranging, 47Hz-63Hz input (high line power only)

N+1 redundant fans (fans integrated in PSU)

Environmental

OPERATING NON-OPERATING

Temperature range 5° to 35°C -30° to 60°C

Humidity 8% to 80% (non-condensing) 8% to 80% (non-condensing)

Shock 3.5g 6ms Pulse vertical shock 8g 6ms Trapezoidal

Vibration Random 0.25 Grms, 510Hz

0.05 g sine wave sweep, 10300Hz

Random 0.6 Grms 10300Hz

Acoustics <7.5dB LwA @ 23ºC

One MB is equal to one million bytes, one GB is equal to one billion bytes and one TB equals 1,000GB (one trillion bytes) when referring to storage capacity.

Accessible capacity will vary from the stated capacity due to formatting and partitioning of the hard drives, the operating system and other factors.

Up to 4 storage enclosures supported for daisy-chaining

Produktspecifikationer

Varumärke:	Western Digital
Kategori:	Diskarray
Modell:	4U60
Produkttyp:	HDD-hölje
Inbyggd display:	Nej
Vikt:	89810 g
Bredd:	424 mm
Djup:	983 mm
Höjd:	174.8 mm
LED-indikatorer:	Ja
USB-anslutning:	Nej
Rackmontering:	Ja
Total installerad lagringskapacitet:	480000 GB
Maximal lagringskapacitet:	480 TB
Rackkapacitet:	4U
Antal lagringsenheter som stöds:	60
Dataöverföringshastighet:	12 Gbit/s
Produktens färg:	Grå
Windows-operativsystem som stöds:	Ja
Temperatur vid drift:	5 - 35 ° C
Temperaturintervall (förvaring):	-30 - 60 ° C
Intervall för relativ operativ luftfuktighet:	8 - 80 %
Fuktighet (förvaring):	8 - 80 %
Strömkälla av typen:	AC
Typ av installerad lagringsenhet:	HDD
Ljudnivå Lc IEC:	7.5 dB
RAID-nivåer:	JBOD
Antal installerade lagringsenheter:	60
AC-adapter, inspänning:	200 - 240 V
Byte under drift (hotswap):	Ja
Lagringsenhetsgränssnitt som stöds:	Seriellt ansluten SCSI
Lagringsenhetens storlek:	3.5 "
AC-adapter, frekvens:	47/63 hz
Installerat lagringsgränssnitt:	Seriellt ansluten SCSI
