Thank you for purchasing this Whale® product. For over 60 years, Whale® has led the way in the design and manufacture of freshwater and waste systems including:

pumps, plumbing faucets, showers for low voltage applications. The company and its products have built a reputation for quality, reliability and innovation backed up by

excellent customer service. Read carefully before installation and use. For information on our full product range visit: www.whalepumps.com

Designed for use in low voltage applications including leisure boats or recreational vehicles such as caravans or motorhomes to pump cold clean freshwater. If it is

intended for use with any other liquid, it is the user’s responsibility to ensure that the materials are fully compatible with the liquids to be used and that a system of safe

working practice is applied to installation, use and maintenance.

CONTENTS

1. Specifi cation

2. Principles of Operation

3. Application

4. Warnings

5. Installation

6. Operation

7. Maintenance

8. Helpful Hints

9. Service Support Details

10. EU Declaration of Conformity, Standards and Approvals

11. Warranty Statement

1

Self-Venting Submersible

& In-Line Booster Pumps

INSTALLATION & USER INSTRUCTIONS

TYPICAL INSTALLATION

LIST OF IMAGES

Fig A. Submersible Pump Installation

Fig B. In-line Pump Installation

1.SPECIFICATION

ModelStandardPremiumPremiumHigh Flow

Product Code UK Specifi cationGP1002GP1352GP1354GP1652

Product Code EU Specifi cationGP1010GP1356GP1358GP1656

Voltage12V d.c.12V d.c.24V d.c.24V d.c.

Recommended Fuse Size5 amp automotive3 amp automotive5 amp automotive

Weight0.15 kg (0.3 lbs)

Hose Connections

Suitable for 10 mm (

3

⁄

8

”) or 13 mm (½”) Flexible Hose

For ½” hose connection:

Fit adaptor by pressing on fi rmly. Note: Once fitted adaptors cannot be removed.

For 15mm Quick Connect Plumbing:

Use WX1511B (Stem Adaptor 11 mm-15 mm). Connect WX1504 (15 mm Equal Straight) and then 15 mm Plumbing

For 12mm Quick Connect Plumbing:

Use Whale part: WU1211B, and connect WU1204 and then 12mm plumbing

Material In Contact with LiquidPump Body: ABS, Seals: Nitrile®, Strainer: Polypropylene, Impeller: PBT, Cable: PVC

Discharge Head

Flow Rate Per Minute

Current Draw

(Note: performance may vary depending on specifi c installations)

0 m (0 ft)

10.3 ltrs13.2 ltrs13.2 ltrs15.75 ltrs

2.4 amps3.6 amps3.8 amps3.8 amps

1 m (3 ft)

8.75 ltrs11.75 ltrs11.75 ltrs14.75 ltrs

2.2 amps3.3 amps1.6 amps3.7 amps

3 m (9 ft)

5.75 ltrs9.75 ltrs9.75 ltrs12.75 ltrs

2.0 amps2.9 amps1.455 amps3.5 amps

Submersible - Model Specifi cations

In Line - Model Specifi cations

ModelIn-Line PremiumIn-Line PremiumIn-Line High Flow

Product CodeGP1392GP1394GP1692

Voltage12V d.c.24V d.c.12V d.c.

Recommended Fuse Size5 amp automotive3 amp automotive5 amp automotive

Weight0.15 kg (0.3 lbs)

Hose Connections

Suitable for 10 mm (

3

⁄

8

”) or 13 mm (½”) Flexible Hose

For ½” hose connection:

Fit adaptor by pressing on fi rmly. Note: Once fitted adaptors cannot be removed.

For 15mm Quick Connect Plumbing:

Use WX1511B (Stem Adaptor 11 mm-15 mm). Connect WX1504 (15 mm Equal Straight) and then 15 mm Plumbing

For 12mm Quick Connect Plumbing:

Use Whale part: WU1211

Material In Contact with LiquidPump Body: ABS, Seals: Nitrile®, Strainer: Polypropylene, Impeller: PBT, Cable: PVC
