LCD/LED 2311W

USER MANUAL

+ GERMAN

+ ENGLISH

+ FRENCH

+ SPANISH

+ ITALIAN

+ RUSSIAN

+ POLISH

+ CZECH

Operation Instructions

Thank you for purchasing this monitor, a high-resolution multi-scan color monitor.

Please read this guide thoroughly before installation.

This monitor has been tested and found compliant with the CE mark. These limits are

designed to provide proper protection against harmful interference to a residential

installation. This monitor generates, uses, and can radiate radio frequency energy. Harmful

interference to radio communication may be led as a result if it‘s not properly installed and

used. However, there is no guarantee that interference will not occur in a particular

installation. If this monitor does cause serious interference to radio or television reception,

resetting the monitor may determine it. Moreover, users are encouraged to correct

interference by doing one or more of the following:

 Reorient or relocate the receiving antenna.

 Move the monitor and the receiver further away from each other.

 Connect the monitor into an outlet on a circuit different from that to which the receiver is

connected.

 Consult your local dealer or an qualified technician.

Warning:

To assure a continued compliance, a user must use a grounded power supply cord and the

provided shielded video interface cable with bonded ferrite cores. Also, any unauthorized

changes or modifications to this monitor would void the user‘s authority to operate this

device.

Note: If necessary, shielded interface cables and AC power cord must be used to meet the

emission level limits.

EU product database for energy label and product information sheet.

2311W ：https://eprel.ec.europa.eu/qr/378017

Content

Safety Precautions ............................................................................................................... 1

First Setup ........................................................................................................................... 2

Quick Installation ................................................................................................................. 3

Installing the LCD Monitor .................................................................................................... 4

Front View of the Product .................................................................................................... 5

Rear View of the Product ..................................................................................................... 6

Using On Screen Display (OSD) Functions ......................................................................... 7

Supporting Timing Modes .................................................................................................. 10

Technical Information......................................................................................................... 11

Care and Maintenance....................................................................................................... 12

Troubleshooting ................................................................................................................. 12

Produktspecifikationer

Varumärke:	Wortmann AG
Kategori:	Övervaka
Modell:	TERRA LED 2311W
Årlig energiförbrukning:	23 kWh
Energieffektivitetsklass (gammal):	A+
Skärm diagonal:	23 "
Upplösning:	1920 x 1080 pixlar
Pekskärm:	Nej
Skärmform:	Platt
Snabbstartsguide:	Ja
Antal färger:	16,78 miljoner färger
Inbyggda högtalare:	Ja
Certifiering:	CE
HDCP:	Ja
HDMI:	Ja
Grafikupplösningar som stöds:	1920 x 1080 (HD 1080)
Vikt (med stativ):	3000 g
Typ av bakgrundsbelysning:	LED
Produktens färg:	Svart
HD-typ:	Full HD
Betraktningsvinkel (horisontell):	178 °
Hörlursutgång:	Nej
Bredd (utan stativ):	533 mm
Höjd (utan stativ):	318 mm
Vikt (utan stativ):	2600 g
Bredd (med stativ):	533 mm
Djup (med stativ):	177 mm
Höjd (med stativ):	408 mm
Skärmtyp:	LCD
VESA-fäste:	Ja
Djup (utan stativ):	46 mm
Paneltyp:	IPS
AC-inspänning:	100 - 240 V
PC-ljud in:	Ja
Växelström Frekvens:	50 - 60 hz
AC-adapter inkluderad:	Ja
Strömförbrukning i vänteläge:	0.5 W
Kontrastförhållande (medel):	30000000:1
Native bildförhållande:	16:9
Max uppdateringsfrekvens:	- hz
Plug & Play-kompatibel:	Ja
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Strömförbrukning i avslaget läge:	0.5 W
Svarstid (medel):	5 ms
Ljusstyrka (normal):	250 cd/m²
Synfältsvinkel (vertikal):	178 °
Kvalitet på VGA (D-Sub) porten:	1
Gränsssnitt för panelmontering:	100 x 100 mm
Stå ingår:	Ja
Höjdjustering:	Nej
Svängarm:	Nej
Antiblåljus-teknik:	Ja
