This document is printed on chlorine-free

(ECF) paper with soy ink.

*Some models may not be available in some countries.

*Colors shown in this catalog may not be represented exactly

as the original colors due to printing processes involved.

*Specifications are subject to change without notice.

yamaha new concept hardware

HI-HAT STANDS TOM HOLDERS CYMBAL STANDS HEXRACK

SNARE STANDS

STOOLS

DOUBLE TOM STANDS

FOOT PEDALS

“Is it really needed?”

That is what we asked ourselves while taking a long, hard look at existing hardware designs. After analyzing and

questioning the necessity of every function it was concluded that too much freedom, too much fineness, can upset

setting stability, interfere with operation.

“The drummer should be able to obtain the desired position and angle, with precision and ease.”

We removed everything but the essentials, focused on sound quality, stability, durability, noise prevention—and

gave them looks that inspire.

Essential functions, refined designs.

New Footboard Design

L-Rod(hxlr)

Drum Arm Clamp (HXTC)

Spring Tension Adjustment

Cymbal Holder and Angle Adjustment

Long & Regular Rods

Adjustable Angle Tilter

Placing type BoomTilter Mechanism

2-Way Beater

Big Rubber Feet

New Step Free Tilter

Placing type BoomTilter Mechanism(CS965, 865, 755)

Retaining YAMAHA s traditional gear mechanism, we now

introduce the ”clipping method for securing the boom

arm.Through this specification, the main unit of the boom

arm becomes more resistant to scratches. It ensures extra

peace of mind, even during complex setup adjustments.It

begins with the CS965, 865, 755.

New Step Free Tilter

Step free angle adjustment lets you set the cymbal at any

position you like. Supporting the cymbal’s weight in the

center of the pipe provides a more stable setting. (CS900

Series, CS800 Series)

Adjustable Angle Tilter

Snare angle adjustment is speedy and flexible. Yamaha’s

exclusive Ball Clamp design on the SS950 lets you set your

snare at any angle you like. The large wing bolt tightens

securely to hold the angle.

2-Way Beater

This convertible beater incorporates two types of beaters

into a single unit. One side is a normal felt type while the

other is made of plastic that delivers a feeling close to

wood. (FP9500, DFP9500 series)

Drum Arm Clamp (HXTC) [ PAT. PENDING ]

Thanks to the ball-mount structure—a distinguishing

feature of YAMAHA hardware--you can adjust the angle to

any degree you want. Because the clamp can easily

removed from (and attached to) the hexagonal tube, it

can be used in any position. Moreover, the standard tom

clamp (CL945 and others) can be attached, as well as the

L-rod provided. (A diameter of 22.2 mm is required for

attachment.)

Spring Tension Adjustment

Spring tension adjustment (the force that opens the top

cymbal) is quick with the large dial. The new design makes

it easy to rotate and an indicator located under the dial

gives you a visual indication of the amount of tension set.

(HS1200T, 1200D, 1200)

Cymbal Holder and Angle Adjustment

The reversible design features felt on one side and rubber

on the other, and can be switched according to you needs.

Also, a newly designed angle adjustment screw automatically

locks after adjustment to prevent loosening during

performance.

Long and Regular Rods

Hi-hat cymbal height

With long rod: 739.5mm-1052mm

With regular rod: 739.5mm-902mm

Two rods, one long one regular, are supplied to

accommodate

lower playing positions.

L-Rod (HXLR)

Hexrod Tom Mounts are included with all HXR configurations

Big Rubber Feet

In addition to the wide leg stance, the big rubber feet

deliver maximum grip to hold the stand securely in place.

Like the tom holder, all double tom stands utilize the triple

hole base.

Yamaha System Hardware Analysis Yamaha System Hardware Analysis

New Footboard Design

The wider pedal design provides a larger contact surface

for your foot delivering a lighter feel and greater playability.

Grip is enhanced in the heel section, and the pattern-less

surface offers both moderate gripping and smooth

movement. A weight balance on the end delivers great

playability. (FP9500 series, DFP8500 series, DFP series)

The FP8500C/8500B both feature longer footboards. The

same length as used on the hi-hat pedals offers smoother

switching to the sub pedal.
