EN User manual
Dishwasher
ZDF 2010
Contents
Safety instructions _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2
Product description _ _ _ _ _ _ _ _ _ _ _ _ _ 3
Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4
Programmes _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4
Options _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5
Before first use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5
Daily use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 7
Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ 10
Troubleshooting _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 10
Technical information _ _ _ _ _ _ _ _ _ _ _ _ 13
Environment concerns _ _ _ _ _ _ _ _ _ _ _ 13
Subject to change without notice.
Safety instructions
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and dam-
ages. Always keep the instructions with the ap-
pliance for future reference.
Children and vulnerable people safety
Warning! Risk of suffocation, injury or
permanent disability.
• Do not let persons, children included, with
reduced physical sensory, reduced mental
functions or lack of experience and knowl-
edge use the appliance. They must have su-
pervision or instruction for the operation of
the appliance by a person who is responsible
for their safety. Do not let children play with
the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appli-
ance door when it is open.
Installation
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Do not install or use the appliance where the
temperature is less than 0 °C.
• Obey the installation instruction supplied
with the appliance.
Water connection
• Make sure not to cause damage to the water
hoses.
• The appliance is to be connected to the wa-
ter mains using the new supplied hose-sets.
Old hose sets must not be reused.
• Before you connect the appliance to new
pipes or pipes not used for a long time, let
the water flow until it is clean.
• The first time you use the appliance, make
sure that there is no leakage.
Electrical connection
Warning! Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information on
the rating plate agrees with the power sup-
ply. If not, contact an electrician.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and exten-
sion cables.
• Make sure not to cause damage to the mains
plug and to the mains cable. Contact the
Service or an electrician to change a dam-
aged mains cable.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure
that there is access to the mains plug after
the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
Use
• This appliance is intended to be used in
household and similar applications such as:
– Staff kitchen areas in shops, offices and
other working environments
2
www.zanussi.com
– Farm houses
– By clients in hotels, motels and other resi-
dential type environments
– Bed and breakfast type environments.
Warning! Risk of injury.
• Do not change the specification of this appli-
ance.
• Put knives and cutlery with sharp points in
the cutlery basket with the points down or in
a horizontal position.
• Do not keep the appliance door open without
supervision to prevent to fall on it.
• Do not sit or stand on the open door.
• Dishwasher detergents are dangerous. Obey
the safety instructions on the detergent
packaging.
• Do not drink and play with the water in the
appliance.
• Do not remove the dishes from the appliance
until the programme is completed. There can
be detergent on the dishes.
Warning! Risk of electrical shock, fire or
burns.
• Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
• Do not use water spray and steam to clean
the appliance.
• The appliance can release hot steam if you
open the door while a programme operates.
Disposal
Warning! Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and dispose of it.
• Remove the door catch to prevent children
and pets to get closed in the appliance.
Customer Care and Service
Contact the Service to repair the appliance.
We recommend only the use of original spare
parts.
When you contact the Service, ensure that you
have the following information that is available
on the rating plate.
Model :
PNC :
Serial Number :
Product description
2
1
3
4
5
10
9
7
8
6
1Worktop
2Lower spray arm
3Filters
4Rating plate
5Rinse aid dispenser
6Detergent dispenser
7Salt container
8Water hardness dial
9Upper spray arm
10 Upper basket
3
www.zanussi.com
Control panel
1
6 5 4
2 3
1On/off indicator
2Programme marker
3Indicators
4Half load button
5Start button
6Programme knob
Indicators Description
End indicator.
Salt indicator. This indicator is off while the programme operates.
Rinse aid indicator. This indicator is off while the programme oper-
ates.
Programmes
Programme Degree of soil
Type of load
Programme
phases
Options
Heavy soil
Crockery, cutlery, pots and
pans
Prewash
Wash 70 °C
Rinses
Dry
Half-load
Normal soil
Crockery and cutlery
Prewash
Wash 65 °C
Rinses
Dry
Half-load
1)
Fresh soil
Crockery and cutlery
Wash 65 °C
Rinse
2)
Normal soil
Crockery and cutlery
Prewash
Wash 50 °C
Rinses
Dry
Half-load
4
www.zanussi.com
Programme Degree of soil
Type of load
Programme
phases
Options
3)
All Prewash
1) With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
2) This is the standard programme for test institutes. With this programme you have the most efficient use of
water and energy consumption for crockery and cutlery with normal soil.
3) Use this programme to quickly rinse the dishes. This prevents the remaining food to bond on the dishes and
bad odours to come out from the appliance.
Do not use detergent with this programme.
Programme
1)
Duration
(min)
Energy
(kWh)
Water
(l)
85 - 95 1.8 - 2.0 22 - 25
100 - 110 1.4 - 1.6 19 - 21
30 0.9 9
130 - 140 1.0 - 1.2 14 - 16
12 0.1 4
1) The pressure and the temperature of the water, the variations of the mains supply, the options and the
quantity of dishes can change the programme duration and the consumption values.
Information for test institutes
For all the necessary information for test performance. send an email to:
info.test@dishwasher-production.com
Write down the product number (PNC) that is on the rating plate.
Options
Half Load
Activate or deactivate the function before
the start of a programme. You cannot acti-
vate or deactivate this function while a pro-
gramme operates.
Set this function when you want to wash a
small quantity of tableware and cookware. The
function decreases the programme duration
and the consumption of energy and water.
Load the upper basket and the lower basket
and decrease the quantity of detergent.
Before first use
1. Make sure that the set level of the water
softener agrees with the water hardness in
your area. If not, adjust the water softener.
Contact your local water authority to know
the water hardness in your area.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Processing residues can stay in the appli-
ance. Start a programme to remove them.
Do not use detergent and do not load the
baskets.
5
www.zanussi.com
Adjusting the water softener
Hard water contains a high quantity of minerals
that can cause damage to the appliance and
bad washing results. The water softener neu-
tralises these minerals.
The dishwasher salt keeps the water softener
clean and in good conditions. Refer to the table
to adjust the water softener to the right level. It
makes sure that the water softener uses the
correct quantity of dishwasher salt and water.
You must adjust the water softener man-
ually and electronically.
Water hardness Water softener
adjustment
German
degrees
(°dH)
French
degrees
(°fH)
mmol/l Clarke
degrees
Manual Elec-
tronic
51 - 70 91 - 125 9.1 - 12.5 64 - 88 2
1)
10
43 - 50 53 - 6376 - 90 7.6 - 9.0 2
1)
9
37 - 42 46 - 5265 - 75 6.5 - 7.5 2
1)
8
29 - 36 36 - 4551 - 64 5.1 - 6.4 2
1)
7
23 - 28 28 - 3540 - 50 4.0 - 5.0 2
1)
6
19 - 22 23 - 2733 - 39 3.3 - 3.9 2
1)
5
1)
15 - 18 18 - 2226 - 32 2.6 - 3.2 1 4
11 - 14 13 - 1719 - 25 1.9 - 2.5 1 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 1 2
< 4 < 5< 7 < 0.7 1
2)
1
2)
1) Factory position.
2) Do not use salt at this level.
Manual adjustment
1 2
Turn the water hard-
ness dial to the posi-
tion 1 or 2.
Electronic adjustment
1. Make sure that the programme marker on
the programme knob is aligned with the on/
off indicator.
2. Press and hold the start button. At the same
time turn the programme knob clockwise
until the programme marker is aligned with
the first programme on the control panel.
3. Release the start button when the start indi-
cator and the on/off indicator start to flash.
• The end indicator flashes intermittently.
The number of flashes shows the level of
the water softener. Example: 5 flashes +
pause + 5 flashes = level 5.
4. To adjust the level of the water softener,
press the start button. Each time you press
the start button you go to the next level.
6
www.zanussi.com
5. To confirm the setting, turn the programme
knob until the programme marker is aligned
with the on/off indicator.
Filling the salt container
Caution! Only use dishwasher salt. Other
products can cause damage to the
appliance.
Water and salt can come out from the salt
container when you fill it. Risk of corrosion. To
prevent it, after you fill the salt container, start a
programme.
1 2
3
Put 1 litre of water in
the salt container (on-
ly for the first time).
4
5 6
Filling the rinse aid dispenser
Caution! Only use rinse aid for
dishwashers. Other products can cause
damage to the appliance.
The rinse aid, during the last rinsing phase,
helps to dry the dishes without streaks and
stains.
1
2
max
M
A
X
1
2
3
4
+
3 4
M
A
X
1
2
3
4
+
To adjust the released quantity of rinse aid,
turn the selector between position 1 (lowest
quantity) and position 4 (highest quantity).
Daily use
1. Open the water tap.
7
www.zanussi.com
2. Press the on/off button to activate the appli-
ance. Make sure that the appliance is in set-
ting mode. Refer to ’SETTING AND
STARTING A PROGRAMME’.
• If the salt indicator is on, fill the salt con-
tainer.
• If the rinse aid indicator is on, fill the rinse
aid dispenser.
3. Load the baskets.
4. Add the detergent.
5. Set and start the correct programme for the
type of load and soil.
Loading the baskets
Refer to the supplied leaflet with examples
of the load of the baskets.
• Only use the appliance to wash items that
are dishwasher-safe.
• Do not put in the appliance items made of
wood, horn, aluminium, pewter and copper.
• Do not put in the appliance items that can
absorb water (sponges, household cloths).
• Remove remaining food from the items.
• Make soft the remaining burned food on the
items.
• Put hollow items (cups, glasses and pans)
with the opening down.
• Make sure that cutlery and dishes do not
bond together. Mix spoons with other cutlery.
• Make sure that glasses do not touch other
glasses.
• Put small items in the cutlery basket.
• Put light items in the upper basket. Make
sure that the items do not move.
• Make sure that the spray arms can move
freely before you start a programme.
Using the detergent
Caution! Use only detergents for
dishwashers.
Do not use more than the correct quantity
of detergent. Refer to the instructions on
the detergent packaging.
1 2
A
3
Put the detergent or
the tablet in compart-
ment (A).
A
B
If the programme has
a prewash phase, put
a small quantity of
detergent in compart-
ment (B).
4
Detergent tablets do not fully dissolve with
short programmes and detergent residues
can stay on the dishes.
We recommend that you use detergent tablets
with long programmes.
Combi detergent tablets
These tablets contain detergent, rinse aid and
other added agents. Be sure that these tablets
are applicable to the water hardness in your
area. Refer to the instructions on the packaging
of the products.
8
www.zanussi.com
Care and cleaning
Warning! Before maintenance, deactivate
the appliance and disconnect the mains
plug from the mains socket.
Dirty filters and clogged spray arms de-
crease the washing results.
Make a check regularly and, if necessary, clean
them.
Cleaning the filters
1
C
B
A
2
3
To remove filters (B)
and (C), turn the han-
dle counterclockwise
and remove. Pull
apart filter (B) and
(C). Wash the filters
with water.
A
4
Remove filter (A).
Wash the filter with
water.
D
A
5
Put filter (A) to its ini-
tial position. Make
sure that it assembles
correctly under the
two guides (D).
6
Assemble filters (B)
and (C). Put them in-
to position in filter
(A). Turn the handle
clockwise until it
locks.
An incorrect position of the filters can
cause bad washing results and damage to
the appliance.
Cleaning the spray arms
Do not remove the spray arms.
If the holes in the spray arms are clogged, re-
move remaining parts of soil with a thin pointed
object.
External cleaning
Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use abra-
sive products, abrasive cleaning pads or sol-
vents.
Troubleshooting
The appliance does not start or it stops during
operation.
Before you contact the Service, refer to the in-
formation that follows for a solution to the prob-
lem.
With some problems, different indicators
flash continuously or intermittently at the
same time to show an alarm code.
10
www.zanussi.com
Produktspecifikationer
| Varumärke: | Zanussi |
| Kategori: | Diskmaskin |
| Modell: | ZDF 2010 |
Behöver du hjälp?
Om du behöver hjälp med Zanussi ZDF 2010 ställ en fråga nedan och andra användare kommer att svara dig
Diskmaskin Zanussi Manualer
4 April 2025
7 Februari 2025
15 Januari 2025
12 Januari 2025
12 Januari 2025
12 Januari 2025
12 Januari 2025
31 December 2025
24 Oktober 2024
23 Oktober 2024
Diskmaskin Manualer
- Tomado
- Everdure
- Logik
- Aspes
- Ilve
- ATAG
- Benavent
- Franke
- Flavel
- Proline
- Electra
- Teco
- Silvercrest
- Samsung
- Nuova Simonelli
Nyaste Diskmaskin Manualer
14 Juni 2025
14 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
12 Juni 2025
