Sida 1/3
BS-858M12/13K
Starlight/WDR 8MP IR Bullet Network Camera
System Overview
Functions
W Series
|
BS-858M12/13K
· 1/1.8” 8MP Sony Starvis Sensor
· H.265+ dual-stream encoding
· IR Eective Range 10~20m
· High Quality Optical Lens 3.6mm/6mm Optional
· IVA (Smart Function) Supported
· Multiple Web Browser Supported, IE/Safari/Chrome/Firefox
· P2P Cloud Function By Mobile App (AntarView Pro)
· Lightning Protection Up to 6KV
· IP67 Ingress Protection
· Built-in PoE
W series 8MP IP cameras are high-end project solution which is powered by Starlight, true WDR smart H.265+ and advanced
cutting-edge Sony sensor for video monitoring.
It delivers crystal clear images and supports industry-leading IVA smart event alarm
Cloud function is built-in for every single device, which is more convenient and exible for real time and remote viewing.
www.zkteco.eu
IP67
3D
DNR
8MP
H.265+
Delivering high quality video with up to 70% lower bandwidth. H.265+ is the optimized evolution of H.265 and traditional H.264.
The Smart H.265+ includes a series of encoding strategy like Dynamic ROI, smart 2D&3D noise reduction.
IVA (Intelligent Video Analysis)
It allows detecting multiple object behaviors, like Face Detection, Tripwire, Intrusion, Objects Detection,Target Counting etc.
Protection
With precise mechanical and rugged casing design, it stands against water and dust with industrial IP67 rank.
Support ±30% input voltage tolerance, it could work safely in extreme unstable power condition.
With working temperature range -30°C to +60 °C, it works well in a variety of harsh outdoor environments.
Camera
BS-858M12K BS-858M13K
1/1.8” 8MP Sony Starvis Sensor
0.06Lux/F1.6(color)
0 Lux with IR on
Flash/DDR
S/N Ratio
IR Distance
IR LED No
128MB/256MB
More than 52dB
10~20m
1
Video
www.zkteco.eu
Technical Parameters
Lens
Focal Length
Aperture
F1.6
FOV
3.6mm 6mm 87° 55°
52°
Video Detection
Audio
Alarm & Audio
Motion Detection, Video Shelter
N/A
IVA
Face Detection/Tripwire/Intrusion/Object Left/Missing/Target Counting
/Sound Detection/Fire Detection/Scene Change/VQD
Network
Ethernet
Onvif
Max. Online Users
Protocols
TCP/IP, UDP, HTTP, IGMP, ICMP, DHCP, RTP/RTSP,DNS,
DDNS, FTP, NTP, PPPoE, UPNP, SMTP, SNMP
1 RJ-45 port
(
10/100Mbps
)
Onvif Prole S
5
Web Broswers
VMS
Mobile App
Platform
IE/Firefox/Chrome/Safari
AntarVis 2.0
AntarView Pro
Mac OS/ Windows/IOS/Android
Working Temperature
Power Consumption
Power Supply
-30 ~+60℃ ℃
＜3W
Ingress Protection
Dimensions
Net Weight
Gross Weight
IP67
160.3 (L)*63.4 (W)*64.5 (H)mm
0.3KG
0.45KG
General
PoE, IEEE802.3af
DC12V±10%
3840(H)* 2160(V)
Eective Pixels
Image Sensor
Model
Min. Illumination
WDR
Day/Night
White Balance
Noise Reduction
120dB
Auto(ICR)/Color/B/W
Supported
3D DNR
Bit Rate
Compression
H.265+/H.265/H.264
Resolution
Bit Rate Control
CBR/VBR
Audio Compression
G.711u
Supported
Supported
BLC
16Kbps-32Mbps
Streaming
Dual stream
Defog
Supported
Digital Zoom
12x
Flip
Mirror
Supported
ROI
Support 4 xed region for main
stream and sub stream separately
Frame Rate
Main stream：
3840x2160
@15fps
Sub stream 704x576：
(
1
~
25/30fps
)
Anti-icker
Privacy Mask
Supported
4 Areas
8MP(3840x2160)/1080P(1920x1080)/1.3M(1280x960)/
720P(1280x720)/D1(704x576)/CIF(352x288)
Working Humidity
10~90%
W Series
|
BS-858M12/13K
Type
Part Number Description
8MP
Camera
Dimensions (mm)
Ordering Information
BS-858M12K
BS-858M13K
8MP Network Camera(3.6mm Lens)
8MP Network Camera(6mm Lens)
-
ZKTECO EUROPE
w
ww.zkteco.eu
E-mail: sales@zkteco.eu
Copyright ©2018 ZKTECO CO., LTD. All rights reserved.
63.4
W Series
|
BS-858M12/13K
