Sida 1/23
R a n g e H o o d
Installation Guide
and Users Manual
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
BUTTON/CONTROL PANEL OPERATION 3
WALL RANGE HOOD INSTALLATION 4
CROWN MOLDING INSTALLATION 9
DESIGNER WALL RANGE HOOD INSTALLATION 10
ISLAND RANGE HOOD INSTALLATION 15
UNDER CABINET INSTALLATION 18
RANGE HOOD INSERT INSTALLATION 21
REMOTE BLOWER INSTALLATION 24
HOW TO CHANGE PARTS 27
TROUBLE SHOOTING AND FAQ’S 39
WARRANTY AND DISCLAIMER
Warranty
Three Year Parts Warranty:
For three years from the date of original purchase, we will provide free of
charge, non-consumable replacement parts for the components that failed due to
manufacturing defects. Subject to the conditions and limitations set forth below at its
option, either repair or replace any part of its products that prove defective by reason
of improper workmanship or material. Repaired parts or replacement products will be
provided by www.therange-hoodstore.com on an exchange basis and will be either
new or refurbished to be functionally equivalent to new. The consumer is responsible
for shipping costs. Consumable parts not covered by this warranty include but are not
limited to: light bulbs, metal, aluminum and charcoal filters.
Who is Covered:
This warranty is extended to the original purchaser for products purchased for
ordinary home use in the continental USA.
This Warranty Will be Void When:
Product damaged through negligence, improper installation, accident, abuse, misuse,
and natural disaster, insufficient or excessive electrical supply. Abnormal mechanical
or environmental conditions or any unauthorized disassembly repair, modifications
or failure to follow the installation instructions or when product is used commercially
or other than its intended purpose or damaged because of improper connection
with equipment of other manufacturers. Repaired or modified by anyone other than
authorized agents This limited warranty does not apply to any product on which
the original identification information has been altered, obliterated or removed, has
not been handled or packaged correctly, has been sold as second-hand or resold
contrary to the US regulations.
What is Not Covered:
Consumable parts such as light bulbs, metal and charcoal filters. The natural wear
of finish, and wear due to improper maintenance, use of corro-sive and abrasive
cleaning products, pads and cleaning products. Chips, dents or cracks due to abuse,
misuse, freight damage (not reported), or improper installation. Damage of product
caused by accident, fire, flood or act of God, we are not liable for and is not covered
by warranty, any loss of properties or any cost associated with removing, servicing,
installing or determining the source of problems with our products.
Proper Venting Regulations
Please verify with your local, city and state regulations on the proper venting
method for your hood. Many agencies have CFM rating specifications for
your hood as well. You may have to purchase additional items on your own to
vent the hood in accordance with your local city and state specifications.
Our ZLINE dual motor range hoods come with an 8” metal transition piece
without a backdraft damper and a piece of 4’ metal ducting.
Our ZLINE single motor units come with a plastic 6” plastic transition piece
with a backdraft damper and a 4’ long piece of flexible ducting.
1
This warranty is valid in the United States. It is non-transferable and applies only
to the purchaser and does not extend to subsequent owners of this product, any
applicable implied warranties, including the warranty of merchantability are limited in
duration to a period of express warranty as provided herein beginning with the date
of original purchase at retail and no warranties, whether express or implied shall be
applied to this product. All shipping charges for returns are the responsibility of the
purchaser.”
Disclaimer
Carefully inspect all items for damages before accepting delivery. Customer
should note any damages on the freight bill or express receipt. Request the name
and signature of the carrier’s agent and keep a copy to support your claim. Upon
acceptance of items, owner assumes responsibility for its safe arrival. Report
damages to the carrier and file a claim immediately. Failure to do so may result in
the denial of your claim. The carrier will furnish you with necessary forms for filing a
claim.
Damages caused during transit are not covered under our warranty. Please contact
us to file an insurance claim.
Please inspect contents of package(s) carefully upon receiving them! We must be
notified of any damages and/or missing parts within (5) days upon your receipt of
package(s). Claims will not be accepted after (5) days. NOTE: Items were thoroughly
tested and carefully packed in our facility before shipping.
Products must be returned in good working condition with ALL original parts and
documentation packed in all original cartons, fillers and shipping cartons. A
restocking fee of 15% will be charged for all approved returns. Exchanges or returns
may not be accepted if any packaging is missing. Make certain to inspect the hood
for damages and defects before installation. Appearance flaws of the hood found
after installation and not affecting the hood’s perfor-mance is not covered under our
warranty for returns or exchanges. Service visits not covered under warranty will
carry a service charge.
Before Installation: Return for exchange or refund.
After Installation: No exchange or refund.
Read all instructions before installing and operating this
appliance.
The installation instructions in this manual is intended for qualified installers, service
technicians or persons with similar qualified background. Installation and electrical
wiring must be done by qualified pro-fessionals and in accordance with all
applicable codes and standards, including first-rated construction.
DO NOT attempt to install this appliance yourself. Injury could result from installing
the unit due to lack of appropriate electrical and technical background.
Range hood may have very sharp edges; please wear protective gloves if it is
necessary to remove any parts for installing, cleaning or servicing.
Activating any switch ON before completing installation may cause ignition or an
explosion.
Due to the size and weight of this range hood, two people installation is
recommended.
To reduce the risk of fire, electric shock, or injury to persons:
For general ventilating use only. DO NOT use to exhaust hazardous or explosive
materials and vapors.
The combustion air flow needed for safe operation of fuel-burning equipment may
be affected by this unit’s operation. Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the National Fire
Protection Association (NFPA), and the American Society of Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code authorities.
Before servicing or cleaning unit, switch power OFF at service panel and lock service
panel to prevent power from being switched ON accidentally.
Ducted fans MUST ALWAYS be vented to the outdoors.
Use only metal ductwork, and this unit MUST be grounded.
Sufficient air is needed for proper combustion and exhausting of gases through the
duct to prevent back drafting.
When cutting or drilling into a wall or ceiling, be careful not to damage electrical
wiring or other hidden utilities.
Your safety and the safety of others is very important. We have provided many
important safety messages in this manual and on your appliance. Always
read and obey all safety messages. All safety messages will tell you what the
potential hazard is, tell you how to reduce the chance of injury, and tell you what
can happen if the instructions are not followed.
Warranty and Disclaimer Important Safety Instructions
