Sida 1/48
H0552400_REVG
WARNING
IF THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY,
A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY
DAMAGE, PERSONAL INJURY, OR DEATH.
FOR YOUR SAFETY: This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which
the product will be installed where such state or local requirements exists. In the event no such state or local requirement exists, the installer or maintainer
must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions in this manual can be followed
exactly. Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow warning notices and
instructions may result in property damage, personal injury, or death. Improper installation and/or operation can create carbon monoxide gas and flue gases
which can cause serious injury, property damage, or death. For indoor installations, as an additional measure of safety, Zodiac Group Australia Pty, Ltd.
strongly recommends installation of suitable carbon monoxide detectors in the vicinity of this appliance and in any adjacent occupied spaces. Improper
installation and/or operation will void the warranty.
• DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
• DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
• DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE
• DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION
WHAT TO DO IF YOU SMELL GAS
• Immediately switch off main gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
INSTALLATION AND
OPERATION MANUAL
Zodiac JXi™
Gas-Fired Pool and Spa Heater
Models 200, 370
Page 2
ENGLISH
Zodiac
®
JXi
™
Gas-Fired Pool & Spa Heater
|
Installation & Operation Manual
Refer to the following websites for information
on warranty and service in your country:
• Australia,NZ,AsiaandSthPacicgotowww.
zodiac.com.au
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL HORSEPOWER
FILTER MODEL
CONTROL PANEL MODEL SERIAL NUMBER
NOTES:
EQUIPMENT INFORMATION RECORD
For full warranty terms and conditions and to register your
warranty, simply visit www.zodiac.com.au/warranty and
complete your details. Or scan the QR code and be taken
directly to the registration page
Record your Equipment details here for quick reference:
Model No.: ____________________________
Serial No.: ____________________________
Page 3
ENGLISH
Zodiac
®
JXi
™
Gas-Fired Pool & Spa Heater
|
Installation & Operation Manual
Table of Contents
Section 1. General Information ....................... 4
1.1 Technical Assistance .......................................... 4
1.2 Warranty ............................................................. 4
1.3 Consumer Information and Safety ...................... 4
1.4 General Operation Description ........................... 4
1.5 Specications ..................................................... 5
1.6 Dimensions ......................................................... 5
1.7 CerticationCodesandStandards ..................... 6
1.8 Heater Components ........................................... 6
Section 2. Getting Started ................................ 7
2.1 Package Contents .............................................. 7
2.2 Required Equipment ........................................... 8
Section 3. Location Requirements .................. 9
3.1 Clearances ......................................................... 9
3.2 Outdoor Installation .......................................... 10
3.3 Indoor and Outdoor Shelter Installation ............. 11
Section 4. Gas Connections .......................... 15
4.1 Supply Gas Requirements ............................... 15
4.2 Inlet Gas Pressure Test .................................... 15
4.3 Special Precautions for LP Gas........................ 16
Section 5. Water Connections ....................... 17
5.1 Pump Sizing ..................................................... 17
5.2 Plumbing Connections ..................................... 18
5.3 Water Pressure Switch Adjustment. ................. 20
5.4 Check Valve Installation ................................... 21
5.5 Pressure Relief Valve (PRV) Installation .......... 21
5.6 Auxiliary Components, Chlorinators, Ozone
Generators and Sanitizing Chemicals .............. 22
Section 6. Electrical Connections ................. 23
6.1 Service Access ................................................. 24
6.2 Bonding ............................................................ 24
6.3 Input Voltage and Conversion .......................... 25
Section 7. Optional Remote Controls ........... 26
7.1 Connecting to a Remote Pool-Off-Spa Selector
(3-Wire Connection) ......................................... 26
7.2 Connecting to a Remote TSTAT (2-Wire
Connection) ...................................................... 26
7.3 Connect to an AquaLink® or “Smart”
Communication via RS-485 ............................. 27
Section 8. Final Installation Check ............... 29
8.1 Operating Instructions ...................................... 29
8.2 Important Safety Information ............................ 29
8.3 First-Time Start-Up Procedure ......................... 29
8.4 To Turn Off Gas To The Heater ........................ 31
8.5 Normal Operation ............................................. 31
8.6 Operating the Controller ................................... 31
8.7 Shutting Down the Heater ................................ 33
Section 9. Maintenance .................................. 34
9.1 Water Chemistry ............................................... 34
9.2 Swimming Pool Energy Saving Tips ................. 35
9.3 Winterizing ........................................................ 36
9.4 Spring Start-up ................................................. 36
9.5 Inspection and Service ..................................... 36
Section 10. Troubleshooting ........................... 38
10.1 Common Problems ........................................... 38
10.2 Service Diagnostic Messages .......................... 39
10.3 Ignition Control LED Service Codes ................. 39
Section 11. Professional Service and
Maintenance .................................. 40
11.1 Header Bypass Reassembly
Recommendations ........................................... 40
Section 12. Spare Parts .................................... 41
12.1 Major Components ........................................... 41
12.2 Cabinet Assembly Spare Parts List and
Exploded Parts Diagram .................................. 42
12.3 Heat System Spare Parts List and Exploded
Parts Diagrams ................................................. 43
12.4 Water System Spare Parts List and Exploded
Parts Diagrams ................................................. 45
12.5 Electrical System Spare Parts List and
Exploded Parts Diagrams ................................ 46
