ZOTAC ZBOX

User’s Manual

No part of this manual, including the products and software described in it, may

be reproduced, transmitted, transcribed, stored in a retrieval system, or translated

into any language in any form or by any means, except documentation kept by the

purchaser for backup purposes, without the express written permission of ZOTAC.

Products and corporate names mentioned in this manual may not be registered

trademarks or copyrights of their respective companies, and are used for identication

purposes only. All trademarks are the property of their respective owners.

Every effort has been made to ensure that the contents of this manual are correct and

up to date. However, the manufacturer makes no guarantee regarding the accuracy of

its contents, and reserves the right to make changes without prior notice.

CAUTION:

Risk of explosion if the battery is replaced with an incorrect type. Batteries should be

recycled where possible. Disposal of used batteries must be in accordance with local

environmental regulations.

ZOTAC ZBOX

Table of Contents

Product specications ----------------------------------------------------------------------------------------3

Safety information ----------------------------------------------------------------------------------------------4

Setting up your system ------------------------------------------------------------------------------------- 4

Care during use ----------------------------------------------------------------------------------------------4

Welcome -----------------------------------------------------------------------------------------------------------5

Package contents -------------------------------------------------------------------------------------------5

Getting to know your ZOTAC ZBOX ----------------------------------------------------------------------6

Front view -----------------------------------------------------------------------------------------------------6

Rear view ------------------------------------------------------------------------------------------------------7

How to disable the ring LED indicator -------------------------------------------------------------------8

Installing hardware inside the ZOTAC ZBOX ----------------------------------------------------------10

Installing a memory module -------------------------------------------------------------------------------11

Removing a memory module -----------------------------------------------------------------------------12

Installing a hard disk drive --------------------------------------------------------------------------------13

Setting up your ZOTAC ZBOX ------------------------------------------------------------------------------14

Positioning your ZOTAC ZBOX ----------------------------------------------------------------------------- 16

Installing the stand ------------------------------------------------------------------------------------------16

Attaching your ZOTAC ZBOX to a display ------------------------------------------------------------16

Installing drivers and software -----------------------------------------------------------------------------17

Installing an operating system ----------------------------------------------------------------------------17

Installing system drivers -----------------------------------------------------------------------------------17

Using your ZOTAC ZBOX ------------------------------------------------------------------------------------- 18

Conguring a wireless connection ----------------------------------------------------------------------18

Conguring a wired connection --------------------------------------------------------------------------19

Using a static IP -----------------------------------------------------------------------------------------19

Using a dynamic IP (PPPoE connection) ---------------------------------------------------------19

Conguring audio output -----------------------------------------------------------------------------------20

Produktspecifikationer

Varumärke:	ZOTAC
Kategori:	Inte kategoriserad
Modell:	ZBOX MI526
Produkttyp:	Mini-PC, barebone
Bredd:	188 mm
Djup:	188 mm
Höjd:	44 mm
Strömförsörjning:	65 W
LED-indikatorer:	HDD, Power, WLAN
Processorfrekvens:	2.4 GHz
Processorfamilj:	7:e generationens Intel® Core™ i3
Wi-Fi:	Ja
Wi-Fi-standarder:	Wi-Fi 5 (802.11ac)
Bluetooth-version:	4.2
Snabbstartsguide:	Ja
Antal HDMI-portar:	1
Processor:	i3-7100U
Intel® Wireless Display (Intel® WiDi):	Ja
Processorns cache:	3 MB
Maximalt internminne:	32 GB
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Smart Response Technology:	Ja
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® InTru™ 3D-teknik:	Ja
Intel® Insider™:	Ja
Intel® AES nya instruktioner (Intel® AES-NI):	Ja
Idle stater:	Ja
Intel® Small Business Advantage (Intel® SBA):	Ja
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Intel® Trusted Execution Technology:	Nej
Intel® Stable Image Platform Program (SIPP):	Nej
Antal processorer som stöds:	1
Antal lagringsenheter som stöds:	1
Minnestyper som stöds:	DDR4-SDRAM
Processorgenerering:	7:e generationens Intel® Core™ i3
Typer av lagringsenheter som stöds:	HDD & SSD
Antal minnesplatser:	2
Typ av minneskort:	SD, SDHC, SDXC
Produktens färg:	Svart
Antal displayportar:	1
VESA-fäste:	Ja
Inbyggd kortläsare:	Ja
processortillverkare:	Intel
Inbyggd processor:	Ja
Antal LAN (RJ-45) anslutningar:	2
processorsockel:	BGA 1356
Processorns kodnamn:	Kaby Lake
Nätverksansluten (Ethernet):	Ja
Likströmsingång:	Ja
AC-adapter inkluderad:	Ja
Strömkabel ingår:	Ja
Intel Clear Video Technology:	Ja
Antal USB 2.0 anslutningar:	1
Minnesplatser, typ:	SO-DIMM
Minnets hastigheter:	1866,2133 MHz
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	3
Moderkortets chipset:	Intel® SoC
Processorkärnor:	2
Bluetooth:	Ja
Nätaggregatstyp:	Extern nätadapter
AC-adapter, nätspänning:	19 V
Processortrådar:	4
Processorlitografi:	14 nm
Värmeavledningseffekt (TDP):	15 W
PCI Express-kortplatser version:	3.0
PCI Express konfigurationer:	1x2+2x1, 1x4, 2x2, 4x1
Grafikadapterfamilj:	Intel
Ombord grafikkort modell:	Intel® HD Graphics 620
Ombord grafikkort:	Ja
Intel® Turbo Boost Technology:	Nej
Förstärkt Intel Speedstep Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Quick Sync Video Technology:	Ja
Intel® Flex minnesåtkomst:	Ja
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Execute Disable Bit-säkerhet:	Ja
Termiska övervakningsteknik:	Ja
CPU konfiguration (max):	1
Inbäddade alternativ:	Ja
Intel Virtualization Technology (VT-x):	Ja
ARK-ID för processor:	95442
Lagringsenhetens gränssnitt:	Serial ATA III
Intel® TSX-NI:	Nej
Storlekar som stöds på lagringsenhet:	2.5 "
Drivrutiner medföljer:	Ja
Kylning typ:	Aktiv
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ C-portar:	2
