Sida 1/2
1
Introduction
ZTE MF30 is a 3G/2G mobile hotspot device, working in GSM/GPRS/EDGE/
WCDMA/HSPA network. The client devices could connect to it via USB or
Wi-Fi interface. The device supports data and SMS services, enabling you to
communicate anytime and anywhere.
This quick guide provides instructions on how to install and get started with
the product. For information about connection of services, please consult
your service provider.
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057
Tel: +86-755-26779999 URL: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
ZTE MF30
Quick Guide
2 4 5 6 73 8
LEGAL INFORMATION
Copyright © 2010 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without the prior written permission of ZTE
Corporation.
The manual is published by ZTE Corporation. We reserve the right to make
modications on print errors or update specications without prior notice.
Version No. : R1.0
Specication
Hardware Installation
Working Mode
9
Notes:
microSD
is a trademark of SD Card Association.
The device’s standby and working time are only for your reference, and
based on ideal working environment.
Getting to Know Your Device
The following gure shows the appearance of the device, it is only for your
reference. The actual device may be different.
Interface and Buttons
1.Power Hold the button to switch on/off the device.Power
2.Memory card slot
(microSD card)
It is where you insert the memory card (microSD
card).
3.WPS
This button is used to start Wi-Fi Protected Setup
authentication process and enable/disable the Wi-Fi
function.
• Hold it for three seconds to activate the WPS
process.
• Press it to enable/disable Wi-Fi function.
4.Charger/USB port
• Charge your device.
• Connect the client to your device via USB cable.
Notes:
Hold the and buttons simultaneously until all LEDs are off, and WPS Power
then release the buttons. The device will restart automatically and restore to
the factory default settings.
LED Indicator
It indicates the status of your device.
When the device is powered on:
Indicator Status Description
Battery
indication
Red blinking Please charge the battery
Red solid Voltage of battery is low
Green blinking Charging
Green solid
Voltage of battery is full(Charging
completed)
Signal strength
indication
Red solid
ERROR or NO signal or NO
network service
Green blinking Signal is ok
Green solid Signal is good
Your device supports three working modes. For the client, we only use PC or
laptop as the example in this document.
USB Mode: Connect to the device with the USB cable.
Wi-Fi Mode: Connect to the device via Wi-Fi.
Establish a connection between your device and the client
Via USB Cable
1. Connect your device and the client with the USB cable.
2. Power on your device.
3. Follow the system prompts to complete the software installation.
Notes:
• If the system does not launch installation automatically, you can run the
installation program in path of .My Computer > Mobile Hotspot
• The driver of your device will be installed at the same time.
4. After the installation, the system will create a shortcut icon on your
desktop and a program group in the Mobile Hotspot Start→Programs
menu. The connection between your device and the client will be
established successfully a moment later.
Via Wi-Fi
1. Power on your device directly. It will take 1~2 minutes to initialize, and
then Wi-Fi LED is blinking.
2. Use your normal Wi-Fi application on the client to search the available
wireless network.
Mixed Mode: Connect to the device with the above two connection methods.
Notes:
If you want to connect to the Internet by using Wi-Fi mode, make sure that
the client supports the Wi-Fi function.
The following picture is the application example. All of the client devices can
surf on the Internet at the same time.
Data Service
HSPA: DL 7.2Mbps
UL 5.76Mbps
WCDMA CS: 64kbps UL/DL
WCDMA PS: 384kbps UL/DL
Interface USB and Wi-Fi
Wi-Fi Standard 802.11b/g
Wi-Fi Security WEP/WPA/WPA2
USB Version USB 2.0 HIGH SPEED
USB Interface Type Mini USB-B
Weight 65g
Dimensions (W×H×D): 99.7mm*53.7mm*13.9mm
microSD card Support up to 32GB microSD card
Power Adapter 5V/700mA
Battery 1500mAh
*Standby time 100hours
*Working time 4hours
Operate system
Windows 7, Windows Vista, Windows XP (SP2 or
later), MAC 10.4 or later
Web Browser
IE (7.0 or later), Firefox (3.0 or later), Opera (10.0
or later), Safari (4.0 or later), Chrome (5.0 or later)
Operating temperature 0°C ~ +35°C
Storage temperature -20°C ~ +50°C
Charging temperature 0°C ~ +45°C
Humidity 5%~ 95%
Wi-Fi indication
Blue blinking Wi-Fi is active
Blue solid WPS is active
LED off Wi-Fi is inactive
Network
indication
Red blinking 2G data transferring
Red solid Register on 2G network
Green blinking 3G data transferring
Green solid Register on 3G network
When the device is powered off and charging:
Indicator Status Description
Battery indication
Green blinking Charging
LED off
Voltage of battery is full(Charging
complete)
Inserting SIM Card and Battery
1. Use the thumb catch at the bottom of the device to open the battery
cover.
2. Insert the SIM card into the SIM card holder.
3. Insert the battery as shown with the contacts located against the metal
springs, and press the battery down into the case.
4. Line the battery cover up correctly and press gently to close the case.
Inserting microSD Card
1. Pull the microSD cover out of the card slot.
Notes:
Do not pull the cover rudely, as it is connected with the device.
2. Insert the microSD card into the microSD slot. The following picture
shows the correct inserting direction. You will hear a click when the
microSD card locks in place.
3. Close the microSD cover.
Switching On/Off Your Device
Hold the button to switch on/off the device.Power
Notes:
The device is powered on when the signal strength indication lights up.
Charging Your Device
You can charge your device by using USB cable or adapter.
1. Insert the charger lead carefully with the plug arrow facing the bottom of
the device.
2. The plug only fits one way. Do not use
excessive force to insert the plug.
3. Make sure the plug is the right way round
and lined up correctly and insert it gently.
