User Instructions

Inno Color Beam LED Introduction

©American DJ Supply® - www.americandj.com - Inno Color Beam LED User Manual Page 2

Rev. 3/14

Unpacking: Thank you for purchasing the Inno Color Beam LED by

American DJ®. Every Inno Color Beam LED has been thoroughly tested

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all accessories necessary to operate

the unit has arrived intact. In the case damage has been found or parts

are missing, please contact our toll free customer support number for

further instructions. Do not return this unit to your dealer without rst

contacting customer support.

Introduction: The Inno Color Beam LED is part of American DJ’s

continuing pursuit for creating high quality affordable intelligent fix-

tures. The Inno Color Beam LED is a high performance, DMX intel-

ligent, moving head LED fixture. This fixture is a great piece for retail

stores, displays, mood, architectural, interior and exterior decoration,

and clubs. This unit can be used as a stand alone, or in a Master/Slave

conguration. The unit can also be controlled via DMX controller. This

fixture is suitable for theaters, studios, retail stores, and other similar

locations.

Customer Support: American DJ® provides a toll free customer sup-

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ®.

PLEASE recycle the shipping carton when ever possible.

Inno Color Beam LED Safety Precautions

©American DJ Supply® - www.americandj.com - Inno Color Beam LED User Manual Page 4©American DJ Supply® - www.americandj.com - Inno Color Beam LED User Manual Page 3

• RGBW Color Mixing

• 36 x 3W High Quatlity CREE LEDs

• Color Strobe Effect

• Color Mix Effect

• Pan/Tilt Inversion

• Electronic Dimming 0-100%

• Dimmer Curve

• Built in Microphone

• DMX-512 protocol

• Two DMX Modes: 1 Channel Mode & 13 Channel Mode

• 3 Operating Modes - Sound Active, Show Mode, or DMX Control

• UC3 Remote Control Compatiable (Not Included)

• Power Cord Daisy Chaining (See Page 19)

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 21 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Inno Color Beam LED Warranty Registration

The Inno Color Beam LED carries a 2 year (730 days) limited war-

ranty. Please fill out the enclosed warranty card to validate your

purchase and warranty. You may also register your product online at

www. americandj.com. All returned service items whether under war-

ranty or not, must be freight pre-paid and accompany a return autho-

rization (R.A.) number. If the unit is under warranty you must provide a

copy of your proof of purchase invoice. Please contact American DJ®

customer support for a R.A. number.

Inno Color Beam LED Features

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this manual

with the unit, for future reference.

Inno Color Beam LED General Instructions

Produktspecifikationer

Varumärke:	Adj
Kategori:	ej kategoriserat
Modell:	Inno Color Beam LED
Produkttyp:	Discostrålkastare
Ursprungsland:	USA
Lampans livslängd:	50000 h
Lämplig för inomhusbruk:	Ja
Spänning:	100 - 240 V
Ljusstyrningsprotokoll:	DMX
Ingångsfrekvens:	50 - 60 hz
Lamptyp:	LED
XLR-ingång:	Ja
Strömkälla:	AC
