User Instructions

Rev. 9/15

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building, and

electrical damages, injuries to any persons, and direct or indi-

rect economic loss associated with the use or reliance of any

information contained within this document, and/or as a result

of the improper, unsafe, unsucient and negligent assembly,

installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

MEGA 64 PROFILE PLUS

ADJ Products, LLC - www.adj.com - Mega 64 Prole Plus User Manual Page 3

• Multi-Colors

• Five Operating Modes

• Electronic Dimming 0-100%

• Built in Microphone

• DMX-512 protocol

• 3-Pin DMX Connection

• Five DMX Modes: 4 Channel Mode, 5 Channel Mode, 6 Channel

Mode, 9 Channel Mode, and 10 Channel Mode.

• ADJ LED RC2 compatiable (Not Included)

• Power Cord Daisy Chain (See page 24)

Mega 64 Profile Plus Warranty Registration

Mega 64 Profile Plus Features

The Mega 64 Profile Plus carries a 2 year limited warranty. Please fill

out the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. The R.A. number

must be clearly written on the outside of the return package. A brief

description of the problem as well as the R.A. number must also be

written down on a piece of paper included in the shipping carton. If

the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our customer support number. All pack-

ages returned to the service department not displaying a R.A. number

on the outside of the package will be returned to the shipper.

The unit should be mounted using a mounting clamp (not provided),

axing it to the mounting bracket that is provided with the unit.

Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10

times the unit’s weight. Also, always use a safety cable that can hold

12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

Mega 64 Profile Plus Installation

Mega 64 Profile Plus Introduction

ADJ Products, LLC - www.adj.com - Mega 64 Prole Plus User Manual Page 2

Unpacking: Thank you for purchasing the Mega 64 Prole Plus by ADJ

Products, LLC. Every Mega 64 Prole Plus has been thoroughly tested

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all accessories necessary to operate

the unit has arrived intact. In the case damage has been found or parts

are missing, please contact our toll free customer support number for

further instructions. Do not return this unit to your dealer without rst

contacting customer support.

Introduction: The ADJ® Mega 64 Profile Plus is part of a continuing

pursuit to create high quality intelligent lighting. The Mega 64 Profile

Plus is a DMX intelligent, high powered LED par fixture. This xture can

be used as a stand alone xture or connected in a Master/Slave con-

guration. This wash has five operating modes: Sound Active mode,

Auto Run mode, RGB+UV mode, Static Color mode, and DMX con-

trolled. To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Customer Support: ADJ provides a customer support line, to provide

set up help and to answer any question should you encounter prob-

lems during your set up or initial operation. You may also visit us on the

web at www.adj.com for any comments or suggestions. Service Hours

are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic Standard

Time.

Voice: (323) 582-3322

Fax: (323) 582-3108

E-mail: support@AmericanDJ.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ Products, LLC.

PLEASE recycle the shipping carton when ever possible.

Produktspecifikationer

Varumärke:	Adj
Kategori:	Effektmaskin
Modell:	Mega 64 Profile Plus
Produkttyp:	Discostrålkastare
Inbyggd display:	Ja
Vikt:	2100 g
Bredd:	260 mm
Djup:	261 mm
Höjd:	110 mm
Sladdlängd:	1.8 m
Antal lampor:	12 lamp(or)
Pulsfunktion:	Ja
Lampans livslängd:	50000 h
Spänning:	100 - 240 V
Ljuslägen:	Auto, DMX, Sound activated
Ljusstyrningsprotokoll:	DMX
Inbyggda makron:	Ja
DMX-ingång:	Ja
DMX-utgång:	Ja
Antal DMX-kanaler:	5 kanaler
Produktens färg:	Svart
Skärmtyp:	LED
Kontrolltyp:	Knappar
ljus färg:	Green, Red
Ingångsfrekvens:	50 - 60 hz
Strömförbrukning (vanlig):	54 W
Lamptyp:	LED
XLR-ingång:	Ja
Strömkälla:	AC
Lampor:	4 W
Spridningsvinkel:	25 °
Antal:	1
Kuldiameter:	- "
Dimbart område:	0 - 100 %
Flimmerfri användning:	Ja
