Sida 1/3
Smart IP Button
(IPBTN-DIS) Installation
Advanced Network Devices • 3820 Ventura Dr. Arlington Hts. IL 60004
tech@anetd.com • 847-463-2237 • www.anetd.com/
1 v1.0
MOUNTING THE DEVICE
• Use device to mark installation location.
• Choose the best location and orientation to
make the push button easy to access by the user,
as well as to connect the network cable.
• Secure device using mounting hardware
appropriate for the installation surface.
• Drywall: #8-32 steel screw x 1-5/8" min. length
fastened to a 75 lbs. rated drywall anchor, or
similar
• Concrete: #8-32 steel screw x 5/8" min. length
fastened to a 8-32 concrete anchor with 9/16"
min. length, or similar
CONNECT TO THE NETWORK
• Connect a network cable (CAT5e or better) to the
RJ-45 port (PoE/PoE+).
• Connect the other end of the network cable to a
PoE (Power over Ethernet) network switch or
PoE injector on a network with a DHCP server.
ACCESS THE DEVICE
Use one of these ways to access the device:
• Enter the IP address assigned by the DHCP server
in your browser.
• Enter the
IPv6 link-local address in your browser,
formatted as
http://[fe80::2246:f9ff:feXX:XXXX] (XX:XXXX =
last 6 digits of MAC address).
• Double-click on the device in the IPClockWise
Endpoints list to open the web server interface.
•
For third-party software application, consult
guide for access method (often uses
configuration file).
CONFIGURATION OPTIONS
The device ships with default settings:
SIP Mode "Button"
Push-to-Talk 1 Trigger Only "Yes”
Activate GPIO 0 During Active Call “Yes”
Send Activations Only “Yes”
GPIO 0 Output Pulse Time “5000”
GPIO 0 Output Blink Period “500”
Indicate GPO “0”
Emergency Indication “SIP”
Indicate Trying Action “Clear”
Indicate Success Action “Blink”
Indicate Unready Action “Clear”
Indicate Ready Action “Set”
Indicate Failure Action “Clear”
Configuration File Setup
<SIPConfig
SIP_mode="button"
push_to_talk_ip1_trigger_mode="1"
gpio0_when_active_call="1" />
<GPIO
pulse_ms_output_gpio0="5000"
blink_ms_output_gpio0="500" />
<GPIO_callback
send_activations_only="1" />
<Indicate
indicate_gpo="0"
trying_action="clear"
success_action="blink"
unready_action="clear"
ready_action="set"
failure_action="clear" />
REGISTRE D SIP CALL
