Square 2x2 Ceiling IP Speaker
(IPS ) Installation CM
Advanced Network Devices 3820 Ventura Dr. Arlington Hts. IL 60004
tech@anetd.com www.anetd.com/ - - 847 463 2237 •
1 v1.0
INSTALLATION
The device ships with a ferrite for
optional usage. For any concerns over
line performance, wrap CAT5/CAT6
Ethernet cable around ferrite once and
Designed for use in drop ceilings.
Cut ceiling tile if needed to
accommodate a 2-foot by 2-foot
space.
Complete the network cable run to
the IPSCM.
Connect the network cable to
Ethernet jack labeled PoE/PoE+.
BUTTON KIT WITH
MICROPHONE (OPTIONAL)
The module on the IPSCM
includes a compatible center
RJ25 port, designed to
connect with the option al
Button Kit with Microphone
(BTN-KIT-MIC-ND) accessory (sold
separately).
To install,
simply
disconnect
the IPSCM
RJ25 plug
from the
center port,
and run an RJ25 cable to the BTN-KIT-
MIC-ND wall plate. See Installation Flyer
for Button Kit with Microphone for
details.
RESOURCES
User Support:
https://www.anetd.com/user-support/
Customer Portal:
https://www.anetd.com/portal/
Technical Resources:
https://www.anetd.com/user-
support/technical-resources/
AND Legal Disclaimer:
https://www.anetd.com/legal/
