1 ADAM-4542+ User Manual
ADAM-4542+
Fiber Optic to RS-232/422/485 Converter
User Manual
Before you begin installing your card, please make
sure that the following materials have been shipped:
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Fiber optic transmission offers the benefits of wide
bandwidth, immunity to EMI/RFI interface, and secure
data transmission. The ADAM-4542+ can be used as
an RS-232/422/485 point-to-point or point-to-multi-
point connection for transmitting and converting full/
half-duplex signals and their equivalents within a fiber
optic environment. Fiber optics are the perfect solution
for applications where the transmission medium must
be protected from electrical exposure, lighting, atmo-
spheric conditions or chemical corrosion.
The ADAM-4542+ is specially designed to link various
machinery equipped with RS-232/422/485 communi-
cation ports (such as computer systems or manufac-
turing machines). Using standard SC connectors, the
module’s fiber optic port can accommodate a wide
range of fiber optic cable. ADAM-4542+ also supports
the redundancy requirement. You can use two pairs of
ADAM-4542+ for a redundant architecture. This spe-
cial design offers higher reliability.
• Compact size
• Direct plug-and-play
• Easily mounted on a DIN-rail, panel, or piggybacked
• Transmission speeds of up to 115.2kbps
• Optical fibers enable transmission of up to 15 km
• Half/Full-duplex, bidirectional transmission mode
• Avoid lightning strikes and EMI/RFI
• Prevents damage from electrostatic discharge
• Stable and error-free data transmission
• Automatic internal RS-485 bus supervision
• No external ow control signals required for RS-485
• Transient suppression and over-current protection on
RS-422/485 data lines
• LED for power and data flow indication
• Fiber Optic : Single Mode
• Wavelength : 1310 nm
• Transmission Distance : 15 km
• Optical Power Budget (attenuation) : min. 8.2 dB
• Casing : ABS with captive mounting hardware
• Communication Mode : Asynchronous
• Connector : Plug-in screw terminal
• Fiber port : SC
• Transmission Mode : Full/Half-duplex, bidirectional
• Transmission Rate : Up to 115.2 kbps
• Power Requirement : Unregulated +10 ~ +30 VDC
• Operating Temperature : -10 ~ 70° C (14 ~ 158° F)
• Operating Humidity : 5 ~ 95% (non-condensing)
• Accessories : DIN-rail mounting adapter, panel mount-
ing bracket
Advantech warrants to you, the original purchaser, that
this product will be free from defects in materials and
workmanship for two years from the date of purchase.
This warranty does not apply to any products which
have been repaired or altered by persons other than
repair personnel authorized by Advantech, or which
have been subject to misuse, abuse, accident or
improper installation. Advantech assumes no liability
under the terms of this warranty as a consequence of
such events.
If your product is defective, it will be repaired or
replaced at no charge during the warranty period.
package and ship it prepaid to your dealer.
Packing List Features
• 1 x ADAM-4542+ Module with DIN-rail mounting
bracket
• 1 x ADAM-4542+ User Manual
• 1 x Panel Mounting Bracket
• 1 x Cable for 9 pin to 3 pin
Introduction
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for ADAM-4542+.
Part No. 2004542001 2nd Edition
June 2004.
Specifications
Two Years Warranty
ADAM-4542+ Fiber Optic to RS-232/422/485 Converter
