AIMB-787 Startup Manual 1
AIMB-787 LGA1200 Intel® Core™ i9/i7/i5/i3 ATX with
Triple Display, Dual GbE LAN, M.2, USB 3.2, DDR4
Startup Manual
Specications (Cont.)
Packing List
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for AIMB-787 at:
http://advt.ch/aimb787spt
Register your products on our website and get 2 months
extra warranty for free at:
http://www.register.advantech.com
This manual is for the AIMB-787 series Rev. A1.
Part No. 2041078701
Printed in China
2nd Edition
February 2023
• SATA interface: Four on-board Serial ATA 3.0 connectors
support data transmission rates of up to 600 MB/s. All
four SATA 3.0 ports support Advanced Host Controller
Interface (AHCI) technology.
• PCIe and PCI slots: 1 PCIe x16 expansion slot, 4 PCIe
x4 expansion slots (three p1-x4 link, one p1-x1 link), 2 PCI slots
32-bit / 33 MHz PCI 2.2 compliant
• USB 3.2/2.0: 2 USB 3.2 Gen 2 ports on rear with up to
10 Gb/s data rate, 4 USB 3.2 Gen 1 ports (2 rear, 2 via
header), 8 USB 2.0 ports (4 rear, 2 via header, 2 internal
Type-A)
• LPC interface: Advantech-designed LPC connector sup-
ports dTPM module
• Serial ports: Six serial ports: COM1, COM2 and COM4 ~
6 are RS-232; COM3 is RS-232/422/485 with jumper and
BIOS menu options.
• Keyboard/mouse connector: The motherboard is not
equipped with rear PS/2 connector for keyboard/mouse.
A 6-pin onboard header is supported for an optional PS/2
keyboard/mouse cable.
• Watchdog timer: 255 sec timer intervals
Graphics Interface
• Chipset: CPU integrated graphics controller
• Display memory: 1 GB maximum shared memory with 2
GB and above system memory installed
• DisplayPort: Resolution up to 4096 x 2304 @ 60 Hz
refresh rate
• DVI-D: Resolution up to 1920 x 1200 @ 60 Hz refresh
rate
• VGA: Resolution up to 1920 x 1200 @ 60 Hz refresh rate
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1: Intel® I219-LM; LAN2: Intel® I210-AT.
Mechanical and Environmental
• Dimensions (L x W): 304.8 x 244 mm (12” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
• Power consumption:
Intel® Core™ i5-10500E; DDR4 16 GB x 4
Maximum: +3.3 V at 5.56 A, +5 V at 4.02 A, +12 V at 6.28 A,
+5 Vsb at 0.16 A, -12 V at 0.1 A
• Operating temperature: 0 ~ 60 °C (depending on CPU)
• Weight of board: 0.7 kg (1.54 lb)
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 AIMB-787 motherboard
• 1 AIMB-787 Startup Manual
• 2 Serial ATA HDD data cables
• 1 I/O port bracket
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Standard Functions
• CPU: LGA1200 socket supporting 10th Gen Intel®
Core™ i9/i7/i5/i3 and Pentium®/Celeron® processors
• BIOS: AMI 256 Mbit SPI BIOS
• Chipset: Intel® Q470E PCH
Note: Legacy platforms are not supported.
• System memory: Up to 128 GB in four 288-pin DIMM
sockets, supporting dual-channel DDR4 2400/2666/2933
SDRAM.AIMB-787supportsnon-ECCunbueredDIMMs
anddoesnotsupportanymemorycongurationthat
mixesnon-ECCwithECCunbueredDIMMs.
• M.2 socket: One M.2 socket supports up to PCIe p1-x4 M-
Key 2280 type storage devices.
