AMAX-4817/4820 Startup Manual 1
Before installation, please check that the following items are
included in the shipment:
1. AMAX-4817/4820 module
2. Terminal blocks (see Specications for more details)
3. Startup Manual
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
For more detailed information about this product, download
the latest user manual from the Advantech website.
The AMAX-4817/4820 ESI le can be downloaded from
the Advantech website at http://www.advantech.com.
Every EtherCAT SubDevice information (ESI) le con-
tains the conguration data of an EtherCAT SubDevice
module. Various EtherCAT communication settings can
be dened from the ESI les of connected SubDevice
units as well as the network connection information. ESI
les are saved to the conguration tool to provide net-
work conguration data. Subsequently, the network
conguration data can be downloaded to the EtherCAT
MainDevice unit for conguring an EtherCAT network.
AMAX-4817/4820
Industrial EtherCAT SubDevice Modules
Startup Manual
The AMAX-4817/4820 series comprises industrial EtherCAT
SubDevice modules equipped with the EtherCAT protocol.
The modules’ compact size and integrated DIN-rail mount
kit ensure easy installation in cabinets. The modules also
feature euro-type pluggable terminal blocks and LED in-
dicators that facilitate system setup and maintenance. All
modules are equipped with an isolation circuit that ensures
current protection for demanding industrial applications.
General
• Connectors
- N x 10-pin terminal block (3.81 mm)
(AMAX-4817 N = 2, AMAX-4820 N = 1)
- 2 x 3-pin screw terminal blocks (3.81 mm)
- 2 x RJ-45 (EtherCAT)
• Dimensions:120 x 120 x 40 mm
3
• OperatingTemperature: -20 ~ 60 °C (32 ~ 140 °F)
• StorageTemperature:-40 ~ 70 °C (-40 ~ 158 °F)
• StorageHumidity:5 ~ 95% RH (non-condensing)
• PowerSupply:10 ~ 30 V
DC
Communications
• Interface:EtherCAT
• DataTransferMedium:Ethernet/EtherCAT cable (CAT5
min.), shielded
• DistanceBetweenModules:100 m max. (100BASE-TX)
• CommunicationCycleTime100 μs
• DataTransferRates:100 Mbps
• Conguration:Not required
AnalogInput(AMAX-4817)
• Channels: 8 channels
• Resolution: 16-bit
• InputVoltageRange:0 ~ 10 V, ±10 V, 0~20 mA, ±20 mA
• Common-ModeInputVoltageRange:±275 V
• MeasuringError: < ±0.1%
• IsolationProtection: 2,500 V
DC
• Bandwidth(-3dB):1.375 kHz/ch
PackingList
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the AMAX-4817 and 4820 modules.
Part No. 2001481702
Printed in China
Edition 3
May 2023
Specications
Overview
UserManual
EtherCATSubDeviceInformationFile
