Sida 1/2
EKI-2701HP-AC Series Startup Manual 1
The EKI-2701HP-AC is a single port IEEE 802.3at/af PoE
injector with internal power supply, able to transfer Ethernet
data and deliver up to 30 watts electrical power to remote
PoE compliant powered devices (PDs) through the Cat.5e
Ethernet cable. It is specically designed for high-power
network equipment, oering a simple, cost-eective, safe, and
reliable power solution for locations where connecting power
supplies is challenging.
Capable of supplying up to 30 watts of power through its
Ethernet port, it can eciently power IEEE 802.3af/at PoE
compliant devices such as wireless access points and IP
cameras, thereby eliminating the need for additional wiring.
Packing List
Before installation, please make sure that you have re- ceived
the following:
• 1 x EKI-2701HP-AC PoE Injector
• 2 x Rubber feett
• 1 x EKI-2701HP-AC Startup Manual
• 1 x Power cord (only for EKI-2701HP-US/EKI-2701HP-
EU/EKI-2701HP-JP)
If anything is missing or damaged, contact your distributor or
sales representative immediately.
EKI-2701HP-AC Series IEEE 802.3at Gigabit PoE
Injector
Startup Manual
General
• Compatibility: IEEE 802.3, 802.3u, 802.3ab, 802.3af,
802.3at
• LAN: 10/100/1000Base-T(X)
• Transmission Distance: Up to 100 m
• Connectors: 2 x 10/100/1000Base-T(X) (DATA IN p1-x1 +
PoE OUT X1)
• Power Input: 100~240Vac,50~60Hz, 0.72A
• Power Consumption: Max. 36W (Full PoE Load)
• Dimensions (W x H x D): 65 x 36 x 140 mm (2.56” x
1.42” x 5.51”)
• Enclosure: IP30
• Operating Temperature: 0 ~ 40°C (32 ~ 104°F)
• Storage Temperature: -20 ~ 70°C (-4 ~ 158°F)
• Operating Humidity: 10 ~ 95% (non-condensing)
• Storage Humidity: 10 ~ 95% (non-condensing)
• Safety: UL62368
• EMC: CE, FCC Class A
• Warranty: 5 year
Overview
Introduction
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com/products/
For technical support and service:
http://www.advantech.com/support/
This manual is for EKI-2701HP-AC.
Part No. 2002270110 2nd Edition
August 2024
Specications
