PCA-AUDIO-HDA1E Startup Manual 1
PCA-AUDIO-HDA1E
7.1 Channel Audio Extension Module
Startup Manual
Before you begin installing your card, please make sure
that the following materials have been shipped:
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Standard Functions
Mechanical
• Dimensions: 47.5 mm x 80.74 mm
Packing ListSpecifications
• PCA-AUDIO-HDA1E Audio Extension Module x 1
• HD Audio Cable x 1p/n:1701120251
• 2 years quality warranty card x 1p/n:2190000902
• Startup manual x 1
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCA-AUDIO-HDA1E Series
Rev. A1.
Part No. 200200HD00
Printed in China
1st Edition
Apr. 2008
#Audio OutputBracket PrintingRear Jack Color
1Line-inLINEBlue
2MIC-inMICPink
3Front-outFRONTGreen
4SPK-outSPEAKGreen
5Back Surround-outREARBlack
6Subwoofer / Center-outSUB CENBlack
7Rear-outSIDEBlack
PCA-AUDIO-HDA1E 7.1 Channel Audio Extension Module
