PCE-3032/PCE-4132 Startup Manual 1
Before you begin installing your card, please ensure the
following items have been shipped:
1. 1 x PCE-3032/PCE-4132 PICMG 1.3 System Host
Board
2. 1 x PCE-3032/PCE-4132 Startup Manual
3. 1 x Serial ATA HDD data cable
4. 1 x 2-port COM cable kit
5. 1 x 4-port USB 2.0 cable kit
6. 1 x Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-3032/PCE-4132 LGA1200 Intel
®
Xeon
®
, Core™
i9/i7/i5/i3/Celeron
®
/Pentium
®
PICMG 1.3 Half-size
System Host Board with DDR4/Dual GbE LAN
Startup Manual
General
• CPU:LGA1200-socket Core™ i9/i7/i5/i3, Pentium
®
and
Xeon
®
W series processors
Note:Only PCE-4132 supports Intel
®
Xeon
®
processors.
• L2Cache: Please refer to CPU specication for detailed
information.
• BIOS: AMI SPI BIOS 256Mb (PCE-4132)/128Mb (PCE-
3032)
• SystemChipset:Intel
®
W480E (PCE-4132)/Intel®
H420E (PCE-3032)
• Systemmemory:
- PCE-4132: Up to 64 GB in 2 x 260-pin SODIMM sock-
ets. Supports dual-channel DDR4 2666/2933 SDRAM
with or without ECC function.
- PCE-3032: Up to 64 GB in 2 x 260-pin SODIMM sock-
ets. Supports dual-channel DDR4 2666/2933 SDRAM
without ECC function.
• SATAharddiskdriveinterface:PCE-3032 supports 3
x SATA 3.0 ports without RAID function, and PCE-4132
supports 4 x SATA 3.0 ports with SW RAID 0,1,5,10.
• Serialports:2 x RS-232 serial ports
• Watchdogtimer:Programmable 1~255 sec
• USB:4 x USB 3.0 and 6 x USB 2.0
• GPIO:1 x programmable 8-bit GPIO pin-header
Display
• Chipset:Intel
®
HD Graphics embedded in the processor.
EthernetInterface
• Chipset supports:
-
LAN 1: Intel
®
I210AT (PCE-3032) and I210AT (PCE-
4132).
-
LAN 2: Intel
®
I210AT (PCE-3032) and I210AT (PCE-
4132).
• Connection: 2 on-board RJ-45 connectors with LED
indicators.
MechanicalandEnvironmental
• Dimensions: (L x W): 172.6 x 126.3 mm/6.7 x 4.97 in
• Power supply voltage: +3.3 V, +5 V, +12 V, 5 VSB
• Power requirements:
CPU:Intel®i7-10700ECPU@2.90GHz,DDR:4GBSO-
DDR4-2666*2
Voltage +V12 +V5_SB +V3.3 +V5
Current 4.36A 0.17A 1.8A 2.13A
• Operating temperature: 0 ~ 60 °C / 32 ~ 140 °F (depend-
ing on CPU)
• Weight: 0.33 kg / 72 lb (weight of board)
SpecicationsPackingList
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
https://www.advantech.com/support
This manual is for the PCE-3032/PCE-4132 Series Rev. A2.
PCE-3032: PCE-4132:
Part No. 2041303201
Printed in China
2nd Edition
October 2022
2 PCE-3032/PCE-4132 Startup Manual
The board has a number of jumpers that allow you to con-
gure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connectors
Label Function
LAN1
PCE-3032: Intel® I210AT
PCE-4132: Intel® I210AT
LAN2
PCE-3032: Intel® I210AT
PCE-4132: Intel® I210AT
VGA VGA connector
COM12 Box header for RS-232*2
FP1
HDD LED, power LED, SNMP SM_Bus,
reset, power on/o
JCASE1 Case open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED connector
HDAUD1 HD audio extension module connector
USB3C1 USB 3.2 port 1
USB3C2 USB 3.2 port 2
USB3H1 USB 3.2 port 3, 4
USB2A1 USB 2.0 port 1
USB2C1 USB 2.0 port 2
USB2H1 USB 2.0 port 3, 4
USB2H2
USB 2.0 port 5, 6
SATA0 Serial ATA0 (SATA 3.0)
SATA1 Serial ATA1 (SATA 3.0)
SATA2 Serial ATA2 (SATA 3.0)
SATA3 Serial ATA3 (SATA 3.0, PCE-4132 only)
CPU CPU Socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B
GPIO1 GPIO pin header
LPC2 Low pin count module expansion pin-header
PWR1 12 V, 5 V power connector
DP2
DVI/DP via optional cable
DP1
Display pin header to stack board (Display
type depends on optional stack board)
EXPCIE1 Mini PCIe pin header to stack board
Jumpers
Label Function
JCMOS1 CMOS clear
JWDT1+JOBS1
Hardware monitor alarm+watchdog
timer output selection
JME1 Enable ME
JCMOS1:ClearCMOS
ClosedPins Result
1-2 Keep CMOS (Default)
2-3 Clear CMOS
JOBS1+JWDT1:Hardwaremonitoralarm+watchdog
timeroutputselection
Function JumperSettings
2-3 Enable watchdog timer (Default)
4-5
Enable Hardware monitor alarm
(Default)
JME1:EnableME
ClosedPins Result
1-2
Enable ME
(Default)
2-3 Disable ME
1 2 3 4 5
1 2 3
JumpersandConnectors
JumpersandConnectors
(Cont.)
