Sida 1/5
PCE-5B19-00 Startup Manual 1
Before card installation, please ensure that the following
items have been shipped:
• PCE-5B19-00A1E startup manual first edition
• M4*6*0.7 round screws P/N: 1939000410
• Two-year quality warranty card P/N: 2190000902
If any of the items are missing or damaged, please contact
your local distributor or sales representative immediately.
Standard Functions
• PICMG 1.3 slots: PCE-5B19-00A1E supports PCE-5000
and 7000 series CPU boards
• PCIe slots: 17 PCIe x16 and 1 PCIe p1-x4
*To enquire about memory, I/O, or IRQ resource limita-
tions, please contact your local Advantech office or FAE
for further support.
• PCIe switch: Four 24-port/96-lane PCIe Gen3.0 switch
for reducing data latency.
• USB (2.0) ports: Four USB ports serving as pin headers
Mechanical and Environment
• Dimensions: 327.66 x 417 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,
5 VSB
• Power requirements: Refer to CPU board, add-on card,
and peripheral documentation
• Operating temperature: 0 ~ 60 °C (depending on the
system thermal solution)
• Weight: 1.22 kg (weight of board)
PCE-5B19-00A1E PICMG1.3 Backplane: 19-slot BP
for 20-slot chassis, 17 x PCIe x16, 1 x PCIe x4
Startup Manual
The backplane features several connectors and jumpers
that facilitate system configuration according to application.
The function of each connector and jumper is listed below.
Connectors
Part Reference Function
SHBA1 ~ SHBD1 PICMG 1.3 CPU board slot
P1PCIEX1 PCIe x16 slot driven p1-x4 PCIe link
P2PCIEX16_1~2 PCIe x16 slot driven x16 PCIe link
P3PCIEX16_1~5 PCIe x16 slot driven x16 PCIe link
P4PCIEX16_1~5 PCIe x16 slot driven x16 PCIe link
P5PCIEX16_1~5 PCIe x16 slot driven x16 PCIe link
EATXPWR1 ATX 2.0 24-pin power connector
EATX12V1~4 ATX 12 V 8-pin power connector
PWR_4P1
ATX 5 V and 12 V 4-pin power
connector
PWR3V1~2 3.3 V Auxiliary power connector
SMBUS1 &
SMBUS2
Chassis sensor board connectors
FAN1 ~ FAN5 Fan connectors
HSFAN1~2 Cooler FAN power connectors
VOLT1 Alarm board/CMM power connector
FANDEC1 Fan detector connector
JFP1 Power and reset button connector
IPMB1 IPMB connector
USB12 USB connector
USB34 USB connector
JP2COMP1/JP-
3COMP1/
JP4COMP1/JP-
5COMP1
Support for non-compliant Gen-1
endpoints enabled
Note: This feature should only be
enabled if a non-compliant Gen-1
device does not linkup when the
data rate identier bits are set.
JP2GEN1/
JP3GEN1/JP-
4GEN1/JP5GEN1
PCIe data rate select
Connectors and Jumpers Packing List
For more information regarding this or other Advantech
products, please visit our website at
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at
http://www.advantech.com/support/
This manual is for PCE-5B19-00A1E.
Part No. 20025B1900
Printed in China
Edition 1
January 2015
Specications
2 PCE-5B19-00 Startup Manual
EATXPWR1
Pin
Name
1 3.3 V
2 3.3 V
3 GND
4 5 V
5 GND
6 5 V
7 GND
8 PWROK
9 5VSB
10 12 V
11 12 V
12 3.3 V
13 3.3 V
14 -12 V
15 GND
16 PSON#
17 GND
18 GND
19 GND
20 -5 V
21 5 V
22 5 V
23 5 V
24 GND
PWR_4P1
Pin
Name
1 12 V
2 GND
3 GND
4 5 V
EATX12V1 ~ EATX12V4
Pin
Name
1 GND
2 GND
3 GND
4 GND
Connectors and Jumpers (Cont.)
5 12 V
6 12 V
7 12 V
8 12 V
PWR3V1 ~ PWR3V2
Pin
Name
1 3.3 V
2 3.3 V
3 3.3 V
4 GND
5 GND
6 GND
VOLT1
Pin
Name
1 5VSB
2 GND
3 GND
4 -5 V
5 5 V
6 3.3 V
7 -12 V
8 12 V
FAN1 ~ FAN5
Pin
Name
1 GND
2 12 V
3 FANIO1 ~ FANIO5
HSFAN1 ~ 2
Pin
Name
1 GND
2 12 V
3 12 V
PCE-5B19-00 Startup Manual 3
Connectors and Jumpers (Cont.)
FANDEC1
Pin
Name
1 FANIO1
2 FANIO2
3 FANIO3
4 FANIO4
5 FANIO5
6 FANIO6
7 FANIO7
SMBUS1 ~ SMBUS2
Pin
Name
1 5 V
2 C-SMBCLK
3 C-SMBDAT
4 GND
JFP1
Pin
Name
1 PWRBTN#
2 GND
3 RESET#
4 GND
IPMB1
Pin
Name
1 IPMB_CLK
2 IPMB_DAT
3 GND
USB12
Pin
Name
1 +5V_USBV01
2 +5V_USBV01
3 USB0-
4 USB1-
5 USB0+
6 USB1+
7 GND
8 GND
9 Null
10 GND
USB34
Pin
Name
1 +5V_USBV23
2 +5V_USBV23
3 USB2-
4 USB3-
5 USB2+
6 USB3+
7 GND
8 GND
9 Null
10 GND
PSON1: ATX/AT Mode Selection
Jumper Setting
Function
1 - 2 closed pins
123
AT mode
2 - 3 closed pins
123
ATX mode (default)
JP (2 ~ 5) GEN1: PCIe Data Rate Selection Jumper
Jumper Setting
Function
1 - 2 Pins Short
123
Gen 3.0(Default)
Pins Open
Gen 2.0
2 - 3 Pins Short
123
Gen 1.0
JP (2 ~ 5) COMP1: PCIe Gen 1 Card Compatibility for
Non-Compliant Gen 1 Endpoints
Jumper Setting
Function
1 - 2 Pins Short
123
For non-compliant PCIe Gen-1
devices
2 - 3 Pins Short
123
For compliant PCIe devices (default)
