PCIE-1158 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
•1 x PCIE-1158 8-port PCIe USB Vision Frame Grabber
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
General
•Chipset:
-4RenesasμPD720202USB3.0hostcontroller
-CompliantwithUSB3.0SpecicationRevision1.0
- Compliant with Intel
®
xHCISpecicationRevision1.0
•Interface:PCIe2.04x
•DataTransferRate:
-SuperSpeed
- High Speed
- Full Speed
- Low Speed
•CurrentProtection:900mAper-portcurrentlimit
Note: For better compatibility, please change the
PCIesettingstoGen2.0ondevicecardslot.
MechanicalandEnvironmental
•Dimensions(LxW):153x106mm
•PowerRequirements:Slot:PCIe2.0standard
•NetWeight:300g
PCIE-1158 8-port PCI Express USB Vision Frame Grabber
Startup Manual
MainBoardConnectors
LabelFunction
USB1~USB8USB3.0Ports1~8
Connector1
AT/ATX12V
DC
input 4-pin power con-
nector
AT/ATX12VDCInput4-pinPowerConnector
PinFunction
Pin 1GND
Pin2GND
Pin3+12V
Pin 4+12V
Figure 1: AT/ATX 12V DC Input 4-pin Power Connector
Figure 2: Slide Switches
ConnectorsPackingList
FormoreinformationonthisandotherAdvantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
ThismanualisforthePCIE-1158SeriesRev.A1
PartNo.2041115800
Printed in China
1st Edition
October2021
Specications
Switch(Reserved)
