ALTV1224C4

AC/DC Dual Output Power Supply

Installation Guide

Rev. 062906

More than just power.

Installing Company: _______________ Service Rep. Name: __________________________________

Address: _____________________________________________ Phone #: __________________

- 2 - ALTV1224C4 Installation Guide

Overview:

Altronix ALTV1224C4 AC/DC Dual Output Power Supply is designed to provide both 12VDC and 24VAC outputs

where a combination of both AC and DC outputs is required. It provides two (2) 12VDC outputs with a total current

of 2A and two (2) 24VAC outputs with a total current of 4A.

Specifications:

Installation Instructions:

1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes

in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place

the enclosure’s upper keyholes over the two upper screws, level and secure. Mark the position of the lower

two holes. Remove the enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s

upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws

(Enclosure Dimensions, pg. 4). Secure enclosure to earth ground.

2. Slide switches SW1, SW2 to the OFF position.

3. Connect the AC (115VAC 50/60Hz) to the two black and white flying leads of the transformers.

4. Measure output voltage before connecting devices. This helps avoiding potential damage.

5. Connect devices to the output terminals using the following procedure:

Connect DC cameras to terminals marked [ + OUT1 –], [+ OUT2 –], carefully observing the correct polarity.

Connect AC cameras to terminals marked [F1 COM1, F2 COM2].

6. Slide switches SW1, SW2 to the ON position.

7. Green LED on the circuit board will illuminate when power is present.

8. Upon completion of wiring, secure enclosure door with screws (supplied).

WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This

installation should be made by qualified service personnel and should conform to the National Electrical

Code and all local codes.

Fuse Replacement:

1. Before replacing fuses slide switches SW1, SW2 to OFF position.

2. Replace AC outputs fuses F1 or F2 with fuses rated @ 3.5A/250VAC.

Replace DC outputs fuses F3 or F4 with fuses rated @ 1A/250VAC.

Terminal Identification:

Terminal Legend Function/Description

XFMR IN Low voltage AC input from two (2) 24VAC / 100VA transformers.

+ OUT1 –, + OUT2 – DC power outputs.

F1 COM1, F2 COM2 AC power outputs.

Input:

• 115VAC 50/60 Hz, 2A.

Output:

• Four (4) individually fuse protected outputs:

- Two (2) outputs @ 12VDC.

- Two (2) outputs @ 24VAC.

• 2A supply current at 12VDC (Fig. 1).

• 4A supply current at 24VAC (Fig. 1).

• Output fuses are rated at:

AC fuses: 3.5A / 250VAC.

DC fuses: 1A / 250VAC.

Visual Indicators:

• AC/DC power LED indicators.

Features:

• Power ON/OFF switch.

• Spare fuses included.

• Unit maintains camera synchronization.

• Ease of installation saves time and

eliminates costly labor.

Enclosure Dimensions (H x W x D):

13.5” x 13” x 3.25”

(342.9mm x 330.2mm x 82.6mm).

Produktspecifikationer

Varumärke:	Altronix
Kategori:	ej kategoriserat
Modell:	ALTV1224C4
Vikt:	5669 g
Bredd:	330 mm
Djup:	83 mm
Höjd:	343 mm
LED-indikatorer:	Ja
Uteffekt:	- W
Spänning:	115 V
Produktens färg:	Grå
Vikt inkl. förpackning:	6123 g
Ingångsfrekvens:	50/60 hz
Utgångsspänning:	12 V
På / av-knapp:	Ja
Anslutningsdetaljer utgång:	4
