WP3 - Outdoor Utility Enclosure

Specifications:

• NEMA4/4X,IP66-11Ratedenclosureforoutdooruse.

• Lightweightmoldedfiberglassreinforcedpolyesterenclosureiscorrosionresistantanddoesnotcontainhalogens.

• Lockablestainlesssteellatches.

• Integralflangessimplifywallorpolemounting.

• Applications:PowerSupplies,BatteriesandAuxiliarymodules.

• Productweight:7.0lbs.(3.18kg).

• Shippingweight:8.3lbs.(3.76kg).

Installation Instructions:

1. Removebackplanefromenclosurepriortomounting(donotdiscardhardware).

2. Markanddrilldesiredinletsontheenclosuretofacilitatewiring(Fig. 1, pg. 1).

3. Mountunitindesiredlocation.Markanddrillholestolineupwiththetopandbottomholesoftheenclosureflange.

 Secureenclosurewithappropriatefasteners(Fig. 2 , pg. 1).

4. Mountcircuitboardstobackplane.

5. Mountbackplanetoenclosurewithhardware.

6. TofacilitatewireentryutilizeweathertightNEMA4ratedconnectors,bushingsandcable.

Fig. 1

Bottom of Enclosure

Suggested Locations

for Wiring Inlets

Wall Mount Installation

1-Placeunitatthedesiredlocationandsecurewithmountingscrews

(not included) (Fig. 2, pg. 1).

Fig. 2

Pole Mounting Using Optional Pole Mount Kit PMK1 (not included):

Thisinstallationshouldbemadebyqualifiedservicepersonnel.Thisproductcontainsnoserviceableparts.PMK1isintended

forusewithAltronixoutdoorratedpowersuppliesoraccessorieshousedinWP1,WP2,WP3andWP4enclosures.Brackets

aredesignedforusewiththeWormgearQuickReleaseStraps(twoincluded).

1. Threadone(1)wormgearquickreleasestrapthroughtheslotsonthebackofamountingbracket(Fig. 3, pg. 1).

2. OncethedesiredheightofthetopPoleMountbracketisachieved,tightenthestrapsdownbyslidingopenendofthe 

 strapthroughthelockingmechanismonthestrap,thentightenthescrewwithflatheadscrewdriveror5/16”hex 

 socketdriver(Fig. 3, pg. 1).

3. Attachthebottombrackettotheenclosurebyinsertingboltsthroughtheflangeoftheenclosureandintothebracket, 

 tighteningboltswitha7/16”hexsocket(Fig. 4, pg. 1).

Fig. 3

Fig. 4

Fig. 5

Altronixisnotresponsibleforanytypographicalerrors.

14058thStreet,Brooklyn,NewYork11220USA,718-567-8181,fax:718-567-9056

website:www.altronix.com,e-mail:info@altronix.com,MadeinU.S.A.

IIWP3-Rev.051112 L22N

MEMBER

1.61”

(40.894mm)

3.96”

(100.584mm)

5.60”

(142.24mm)

10-32 X 0.375” (9.525mm)

BRASS INSERT (X4)

STAINLESS STEEL PIANO HINGE

11.32” (287.528mm)

13.32”

(338.328mm)

PADLOCK LATCH ATTACHED

WITH RIVETS (Ø 0.375” (9.52mm) PADLOCK EYE).

10.75” (273.05mm)

10.00” (254mm)

8.25” (209.55mm)

10.25”

(260.35mm)

12.00”

(304.8mm)

13.50”

(342.9mm)

10-32 X 0.25” (6.35mm)

BRASS INSERT (X2)

Ø 0.32 (8.128mm) MOUNTING HOLE

TYP. 4 PLACES

12.75”

(323.85mm)

8.00” (203.2mm)

Enclosure Dimensions (H x W x D approximate):

13.3”x11.3”x5.6”(338.1mmx287.3mmx142mm)

4. Threadthesecondwormgearquickreleasestrapthroughtheslotsonthe

 backofthebottommountingbracket(Fig. 6, pg. 2).

5. Mountenclosureontothetopbracketbyinsertingboltsthroughflangeoftheenclosure

 andintothebracket,tighteningboltswitha7/16”hexsocket(Fig. 6, pg. 2).

6. Tightenthestrapsofthebottombracketdownbyslidingtheopenendof

 thestrapthroughthelockingmechanismonthestrap,thentightenscrew

 withflatheadscrewdriveror5/16”hexsocketdriver(Fig. 7/7a, pg. 2).

7. Clipexcessstraps.

Fig. 7 - 2” to 8”(50.8mm to 203.2mm) Fig. 7a - 5” (127mm)

diameter round pole square pole

Fig. 6

Produktspecifikationer

Varumärke:	Altronix
Kategori:	ej kategoriserat
Modell:	WP3
Vikt:	3180 g
Bredd:	287 mm
Djup:	142 mm
Höjd:	338 mm
Material:	Polyester
Produktens färg:	Grå
Internationellt skydd (IP) kod:	IP66
