Version 1.1 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather RC-8427 ClearView Radio Controlled
Projection Alarm Clock with Indoor Temperature User
Manual
Table of Contents
1. Introduction ..................................................................................................................................... 1
2. Warnings ......................................................................................................................................... 2
3. Getting Started ................................................................................................................................ 2
3.1 Parts List ................................................................................................................................. 2
3.2 Powering Up ................................................................................................................................. 2
3.2.1 Radio Controlled Clock (RCC) .............................................................................................. 2
3.2.2 Clock Layout ...................................................................................................................... 3
4. Operational Modes .......................................................................................................................... 4
4.1 Normal Time Mode ................................................................................................................ 4
4.2 Alarm Time Mode .................................................................................................................. 4
5. Settings ............................................................................................................................................ 4
5.1 Time Zone Settings................................................................................................................. 4
5.2 Daylight Time Zone Settings .................................................................................................. 5
5.3 Time and Date Settings .......................................................................................................... 5
5.4 Alarm Settings ........................................................................................................................ 6
5.5 Using the Alarm and Snooze Functions ................................................................................. 6
5.6 Projector and Backlight .......................................................................................................... 6
5.6.1 Using the Projector and Backlight ..................................................................................... 6
5.6.2 Projector Backlight Rotation .............................................................................................. 7
5.6.3 Adjusting Backlight Focus ................................................................................................. 7
5.7 Low Battery Indictor .............................................................................................................. 7
6. Specications .................................................................................................................................. 7
6.1 Measurement Specications ......................................................................................................... 7
6.2 Power Consumption ...................................................................................................................... 7
7. Troubleshooting Guide .................................................................................................................... 7
8. Accessories ..................................................................................................................................... 8
9. ability Disclaimer ........................................................................................................................ 8 Li
10. Warranty Information ................................................................................................................. 9
1. Introduction
Thank you for your purchase of the Ambient Weather RC-8427 ClearView Radio Controlled
Projection Clock with Indoor Temperature. The following user guide provides step by step instructions
for installation, operation and troubleshooting. To download the latest full sized manual and additional
troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/rc8427
Version 1.1 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 2
2. Warnings
Warning. Never look directly into the time and temperature projector. This can cause
temporary blindness.
Warning. Only use approved AC adapter.
3. Getting Started
3.1 Parts List
QTY
Item
1
Clock
Frame Dimensions (LxWxH) 5" L x 2"D x 3.5"H :
1
UL Rated AC Adapter
1
User Manual
Figure 1
3.2 Powering Up
1. Plug the AC adaptor into the DC jack of the clock.
2. Remove the battery door on the bottom of the clock and insert 2 new AA batteries, according
to the polarity information marked on the battery compartment, and replace the battery door.
3. Once the batteries are inserted, all of the LCD segments will light up briey before entering
the radio controlled clock (RCC reception mode. )
4. The RCC clock clock 2:00am and will attempt to synchronize with the RCC. will
The clock will automatically search for the time signal at 2:00, 8:00, 14:00 (2pm) and 20:00
(8pm).
Note: If no display is present after powering up the clock, press the reset key on the back of the
clock with an open ended paper clip or sharp tool.
3.2.1 Radio Controlled Clock (RCC)
Eight seconds after power up, the clock begin radio controlled clock (RCC) reception and the RCC
search icon will turn on. The RCC will continue to search for six minutes. It will try again
every two hours.
RCC Icon
Description
RCC Icon
Description
No signal
Acceptable signal
Weak signal (ashes between
two icons). Cannot be
interpreted.
Excellent signal
Figure 2
If the time is incorrect by increments of an hour, or does not change on your radio controlled clock
(RCC), please reference Section 7, Troubleshooting Guide.
Version 1.1 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 3
3.2.2 Clock Layout
No
Description
No
Description
1
LCD. Time, alarm time, date, day of week
and temperature.
9
RESET key. In the event of malfunction,
press the reset key with an open ended
paper clip or sharp object to restore to
factory default.
2
MODE key. Switch between normal time
mode and alarm time mode.
10
REVERSE key. Press to reverse the
projected data 180 degrees.
NOTE: You must press the
SNOOZELIGHT key first, before pressing
the REVERSE key.
3
SET key.
In normal time mode, press to switch
between °C and °F.
In time set mode, press to change the
time settings.
11
PROJECTION ON/OFF slide switch.
This function is only available when
connected to the AC adapter.
Slide to position to project ON
continuously, or to turn o projected OFF
data.
4
ADJUST key.
In set mode and alarm set mode, press to
increase the set values. Press and hold to
change rapidly.
In normal mode, press to display year for 30
seconds.
12
BACKLIGHT ON.
This function is only available when
connected to the AC adapter.
Slide to position to display backlight ON
continuously, or to turn o. OFF
5
RECEIVE key. Press to search for the
RCC signal..
13
L/H slide switch. Sets backlight brightness
to low or high.
Slide to L position for low backlight.
Slide to H position for high backlight.
6
PROJECTOR. Projects the time and
temperature.
14
DC jack. Plug the DC adaptor in to power
the clock.
7
FOCUS knob. Adjusts the focus of the
projected time and temperature.
15
Battery compartment.
8
SNOOZE/LIGHT key.
Press to turn on the projector and backlight
for 5 seconds.
When the alarm is sounding, press to stop
current alarm and turn to snooze.
Figure 3
