Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather F007T 8-Channel Wireless
Thermometer User Manual
Table of Contents
1 Introduction ..................................................................................................................................... 2
2 Getting Started ................................................................................................................................ 2
2.1 Parts List ....................................................................................................................................... 2
2.2 Probe Thermometer Sensor Set Up ............................................................................................... 2
3 Remote Sensor Installation ............................................................................................................. 4
4 Glossary of Terms ........................................................................................................................... 4
5 Specications .................................................................................................................................. 4
5.1 Wireless Specications ................................................................................................................. 4
5.2 Measurement Specications ......................................................................................................... 5
5.3 Power Consumption ...................................................................................................................... 5
6 Troubleshooting Guide .................................................................................................................... 5
7 Liability Disclaimer ........................................................................................................................ 6
8 FCC Statement ................................................................................................................................ 6
9 Warranty Information ...................................................................................................................... 7
Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 2
1 Introduction
Thank you for your purchase of the Ambient Weather T 8-Channel Wireless Thermometer. The F007
following user guide provides step by step instructions for installation, operation and troubleshooting.
To download the latest manual and additional troubleshooting tips, please visit the FAQ website:
http://ambientweather.wikispaces.com/f007t
The F007T transmits wirelessly to any compatible Ambient Weather receiver, including the WS-07,
WS-08, WS-09 and WS-10 wireless weather station display consoles. Other console models may be
added later, and will be listed on the FAQ website.
2 Getting Started
Note: The power up sequence must be performed in the order shown in this section (insert
batteries in the remote transmitter rst, Display Console second). (s)
2.1 Parts List
QTY
Item
1
Thermometer transmitter (FT007T)
Dimensions (LxHxW): 4.5” x 2.0” x 0.75”
2
User Manual
2.2 Probe Thermometer Sensor Set Up
Note: Do not use rechargeable batteries. We recommend fresh alkaline batteries for temperature
ranges between -4 and 140 and fresh lithium batteries for temperature ranges between -40 °F °F °F
and 140 °F.
1. Remove the battery door on the back of the sensor by removing the set screw, as shown in
Figure 1 .
Figure 1
2. inserting the batteries, locate the dip switches on the inside cover of the lid of the BEFORE
transmitter.
Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 3
Figure 2 displays all four switches in the OFF position (factory default setting).
Figure 2
3. The sensor supports up to eight transmitters. To set each channel number Channel Number:
(the default is Channel 1), change Dip Switches 1, 2 and 3, as referenced in Table 1.
4. Temperature Units of Measure: To change the transmitter display units of measure ( °F
vs. °C), change Dip Switch 4, as referenced in Table 1.
DIP SWITCH
FUNCTION
1
2
3
4
DOWN
DOWN
DOWN
---
Channel 1
DOWN
DOWN
UP
---
Channel 2
DOWN
UP
DOWN
---
Channel 3
DOWN
UP
UP
---
Channel 4
UP
DOWN
DOWN
---
Channel 5
UP
DOWN
UP
---
Channel 6
UP
UP
DOWN
---
Channel 7
UP
UP
UP
---
Channel 8
---
---
---
DOWN
°F
---
---
---
UP
°C
Table 1
5. Insert two AAA batteries.
6. After inserting the batteries, the remote sensor LED indicator will light for 4 seconds, and
then ash once per 60 seconds thereafter. Each time it ashes, the sensor is transmitting data.
7. Verify the correct channel number (CH) and temperature units of measure (°F vs. °C) are on
the display, as shown in Figure 3.
Figure 3
