HCG- M P S 520 OWER UPPLY

U M SER’S ANUAL

HCG M SERIES

HCG- M P S 520 OWER UPPLY

E LITE POWER MEETS UNRIVALED PERFORMANCE

Antec’s HCG M power supplies are the perfect combinaon of power and eciency. The HCG M features special

heavy-duty High Current connectors and cabling that supply extreme levels of power, and superb eciency thanks

to 80 PLUS® Bronze cercaon and Acve PFC. Highest-quality connectors, Japanese-brand capacitors, and a

quiet 135 mm double ball bearing fan complete the package. The HCG-520M features High Current Cable

Management and 10-pin modular connectors. If loads of power, High Current engineering and extreme eciency

are what you’re aer, the HCG M is the PSU for you.

S F TANDARDS AND EATURES

The connectors and power specicaons of the HCG- M PSU are all compable with ATX12V v2.32 and EPS12V 520

v2.92 specicaons. The HCG- M features Universal Input, which automacally senses when you connect the 520

power supply to any AC power source between 100 - 240V without seng a voltage switch. This power supply also

features Acve Power Factor Correcon (PFC), which improves the power factor value of the power supply by

altering the input current wave shape, helping to power transmission across the grid.

S P YSTEM ROTECTION

A variety of industrial-grade safety circuitry will help protect your computer: Over Current Protecon (OCP), Over

Voltage Protecon (OVP), Under Voltage Protecon (UVP), Short Circuit Protecon (SCP), Over Power Protecon

(OPP) and Surge & Inrush Protecon (SIP). Somemes the PSU will “latch” into a protected state. You will need to

power o the PSU and clear the fault before it will funcon again. There are no user-replaceable fuses in your

HCG- M. 520

80 PLUS® C ERTIFICATION

80 PLUS® cercaon is the most widely recognized

independent standard in power supply eciency. An 80

PLUS® cered power supply uses less energy and

generates less heat to stay cooler, run quieter and last

longer. The HCG- M has been 80 PLUS® Bronze 520

cered to be at least 82% ecient at a wide range of

operang loads; this will lower your operang costs and

help protect the environment.

P O OWER UTPUT

To see the output capacity and regulaon for each dierent voltage, see table 1.

T 1 ABLE

Output Voltage

Load Max.

Regulaon

Ripple & Noise

+3.3V

24A

±5%

< 50 mV

+5V

24A

±5%

< 50 mV

+12V

40A

±5%

< 120 mV

- 12V

0.8A

±5%

< 120 mV

+5VSB

2.5A

±5%

< 50 mV

I H C M NTELLIGENT YBRID ABLE ANAGEMENT

The HCG-520M uses Intelligent Hybrid Cable Management. Cables that are important or mandatory are

permanently connected to the PSU for the highest quality power delivery. There are modular jacks on the back of

the PSU to add addional cables as needed. Using only the cables you need will reduce cluer and improve airow

inside your case. For the list of connected and oponal cables, see table 2.

M C J ODULAR ABLE ACKS

There are two 5-pin black jacks and four 10-pin red jacks on the back of your HCG- M PSU. These jacks are for 520

the oponal cables that come with your power supply. A modular 10-pin connector system allows you plug 5-pin

connectors into the 10-pin jacks if you run out of 5-pin jacks.

Produktspecifikationer

Varumärke:	Antec
Kategori:	Dator strömförsörjning
Modell:	HCG-520M
Vikt:	1800 g
Bredd:	150 mm
Djup:	160 mm
Höjd:	86 mm
Medeltid mellan fel (MTBF):	100000 h
Effektfaktor:	0.99
Effektivitet:	88 %
Power Factor Correction (PFC) typ:	Aktiv
EPS-version:	2.91
Spänningstolerans:	10 %
Produktens färg:	Svart
Effekt skyddsfunktioner:	Over current, Over power, Over voltage, Short circuit, Under voltage
Hållbarhetscertifiering:	RoHS, ENERGY STAR
AC-inspänning:	100 - 240 V
Fläktdiameter:	135 mm
Växelström Frekvens:	50 - 60 hz
På / av-knapp:	Ja
Ljudnivå Lc IEC:	- dB
ATX-version:	2.3
EPS strömkontakt (8-polig):	Ja
Ingående ström:	8 A
Antal fläktar:	1 fläkt/-ar
Ändamål:	PC
Elektromagnetisk kompatibilitet:	cUL, TUV, CE, CB, FCC, C-TICK, CCC, BSMI, Gost-R
Total effekt:	520 W
Kylning typ:	Aktiv
Periferiska (Molex) strömkontakter (4-pin):	6
Antalet SATA strömkontakter:	6
Kombinerad effekt (+3,3 V):	130 W
Kombinerad effekt (+12 V):	480 W
Kombinerad effekt (+5 V):	130 W
Max utström (+3,3 V):	24 A
Max utström (+12 V):	40 A
Max utström (+5 V):	24 A
Max utström (-12V):	0.8 A
Max utström (+5 VSB):	2.5 A
Strömförsörjningsenhet formfaktor:	ATX
Moderkort strömkontakt:	20+4 pin ATX
PCI Express strömkontakter (6 +2 pin):	2
CPU strömkontakt (4 +4 pin):	Ja
Typ av kablage:	Semimodulär
Stöd för parallellprocessteknik:	2-Way CrossFireX, 2-Way SLI
80 plus-certifiering:	80 PLUS Bronze
Anslutning för diskettenhet:	Ja
PCI expressanslutning:	Ja
Fan plats:	Övre
Diskettenhet strömkontakt:	1
ATX strömkontakt (20 4 stift):	Ja
Högsta ingångsström (vid 110V):	+12V, +3.3V, +5V, +5Vsb, -12V A
CPU P4-kontakt (4-stifts):	2
Övervaka utlopp:	Ja
