Documentation Supplement for

Marine Smart-UPS™

SRT5KRMXLIM, SRT6KRMXLIM

External Battery Pack

SRT192RMBPM

Product Description

The information in this documentation supplement applies to specific APC™ by Schneider Electric DNV-GL

Type Approved Uninterruptible Power Supply (UPS) models, external battery packs (XLBP), companion EMI

filters and the tower installation kit.

The tower installation kit is used only for UPS models in tower configurations.

The APC by Schneider Electric products listed in the table below meet DNV-GL Type Approval 2.4 requirements.

When these specified UPS models are used with the appropriate companion filter and tower installation kit they

are approved for use on the bridge, in control rooms and in accommodation zones.

SKU Description

SRT5KRMXLIM Marine Smart-UPS SRT 5000 VA, 230 Vac, Rack-Mount

SRT6KRMXLIM Marine Smart-UPS SRT 6000 VA, 230 Vac, Rack-Mount

SRT6M Marine Filter for use with Smart-UPS UPS models:

SRT5KRMXLIM/SRT6KRMXLIM

SRT10BDVK Marine Secure Bolt Down Vibration Isolation kit for Smart-UPS

UPS models:

SRT5KRMXLIM,SRT6KRMXLIM

XBP model:

SRT192RMBPM

SRT192RMBPM Marine external battery pack for use with Smart-UPS models:

SRT5KRMXLIM, SRT6KRMXLIM

SRT10IP23 SRT10IP23 enclosure for use with Smart-UPS models SRT5KRMXLIM,

SRT6KRMXLIM

Documentation Supplement2

Specifications

When the APC by Schneider Electric Marine UPS models listed in the table on the previous page are used with the

appropriate companion filter, the specifications in this marine application supplement supersede the specifications

listed in the UPS user manual supplied in the carton with the SRT products.

The APC by Schneider Electric Marine UPS and XLBP models listed in the table on the previous page, are capable of

operating at temperatures up to 55º C for up to 16 hours in a 24 hour period. This meets the DNV-GL Type Approval

2.4 temperature Class A requirements.

Operation at a temperature above 40º C requires the UPS power output to be de-rated.

• 0º C to 40º C (32º F to 104º F) at 100% rated output power

• 40º C to 55º C (104º F to 131º F) de-rate output power 2.5%/º C (1.38%/º F)

The UPS and XBP models are capable of operating at elevated temperatures.

However, expected battery life drops by 50% for every 10º increase in ambient temperatures

above 25º C (77º F).

For maximum runtime capability avoid operating the UPS and XBP models at temperatures

above 40º C (104º F).

Certifications

EAC

RCM

DNV-GL

For DNV-GL Type Approval certificate go to the APC web site, www.apc.com.

IEC 60945 recommended compass distances

Input Voltage Range (Full Load, t=40º C) 160 V to 280 V

Input Voltage Range (Half Load, t=40º C) 100 V to 280 V

Input Voltage Range (Full Load, t=55º C) 180 V to 280 V

Input Voltage Range (Half Load, t=55º C) 112.5 V to 280 V

SRT5KRMXLIM 258 cm

SRT6KRMXLIM 247 cm

Documentation Supplement 3

Installation

For rack-mount installation instructions refer to the UPS or XLBP installation guide supplied with this XLBP.

Tower Configuration

For shipboard tower installation, APC by Schneider Electric offers a secure bolt down vibration isolation kit,

SRT10BDVK.

The installation guide is supplied in the carton with the SRT10BDVK kit.

The installation guide is also available;

~on the APC web site www.apc.com

~on the Documentation CD supplied in the carton with the SRT10BDVK kit.

SRT5KRMXLIM +

SRT6M + SRT10BDVK

SRT6KRMXLIM +

SRT6M + SRT10BDVK

SRT192RMBPM +

SRT10BDVK

Produktspecifikationer

Varumärke:	Apc
Kategori:	ej kategoriserat
Modell:	SRT192RMBPM
Vikt:	910000 g
Bredd:	432 mm
Djup:	682 mm
Höjd:	130 mm
Förpackningens bredd:	600 mm
Uteffekt:	- W
Rackkapacitet:	3U
Produktens färg:	Svart
Låddjup:	1000 mm
Vikt inkl. förpackning:	105000 g
Formfaktor:	Rackmonterad
Ingångsfrekvens:	- hz
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-15 - 45 ° C
Intervall för relativ operativ luftfuktighet:	0 - 95 %
Fuktighet (förvaring):	0 - 95 %
Harmonized System (HS)-kod:	85078000
Uteffekt kapacitet (VA):	6 kVA
Inmatning spänning (min):	- V
Inmatning spänning (max):	- V
Utgång, driftspänning (min):	- V
Utgång, driftspänning (max):	- V
Batteriets livslängd (max):	5 År
