SPLITTY9
Instruction manual Splitty9
Instruction manual Splitty9Instruction manual Splitty9
Instruction manual Splitty9
Splitty9 is a universal ninefold splitter and can be used for 3-pin
fans, 4-pin PWM fans or as an aquabus splitter.
Fan splitter application
Fan splitter applicationFan splitter application
Fan splitter application
Connect the white connector marked with the word “input” to a
fan output using the supplied cable. Power supply and PWM
signal (if available) are provided to all nine black connectors,
additionally the speed signal received from the connector
marked “rpm” is forwarded to the fan output. Make sure the
jumper is not set to the “aquabus” position!
aquabus splitter application
aquabus splitter applicationaquabus splitter application
aquabus splitter application
Connect the white connector marked with the word “input” to
the aquabus connector of an aquaero using the supplied cable.
By setting the jumper to the “aquabus” position, all four
aquabus signal lines are forwarded to all black connectors. The
splitter can be used for 4-pin as well as 3-pin aquabus devices.
Installation
InstallationInstallation
Installation
Use the self-adhesive hook-and-loop strip included in delivery
for easy installation, alternatively four mounting holes can be
used.
Notice: Do not exceed the splitter's maximum current rating of 5
Notice: Do not exceed the splitter's maximum current rating of 5Notice: Do not exceed the splitter's maximum current rating of 5
Notice: Do not exceed the splitter's maximum current rating of 5
A! Observe the maximum rating of the fan output as well when
A! Observe the maximum rating of the fan output as well whenA! Observe the maximum rating of the fan output as well when
A! Observe the maximum rating of the fan output as well when
connecting multiple fans!
connecting multiple fans!connecting multiple fans!
connecting multiple fans!
Aqua Computer GmbH & Co. KG© 2016
Gelliehäuser Str. 1, 37130 Gleichen
