ULTITOP D5
ULTITOP D5
ULTITOP D5ULTITOP D5
ULTITOP D5
User and installation manual
User and installation manualUser and installation manual
User and installation manual
Description
DescriptionDescription
Description
Exceptionally compact top for D5 pumps, made from durable acetal (41123) or
velopment of the ULTITOP D5 were optimum flow characteristics, reducing noise
and vibration to a bare minimum.
A fastening ring made from anodized aluminum and a gasket are supplied to at-
tively preventing remaining vibrations from being transmitted to the PC case. Stain-
less steel plates with M3 threads inserted into the decouplers ensure convenient in-
stallation. The bracket can be detached from the ULTITOP by removing a single
screw for easy access to the pump.
Installation of a D5 pump motor
Installation of a D5 pump motorInstallation of a D5 pump motor
Installation of a D5 pump motor
If you have a complete D5 pump instead of a D5 pump motor, you will have to
disassemble the pump first. The only parts needed are the housing with electronic
components and the impeller.
Install the pump motor as follows:
1. Place the gasket into the ULTITOP base part.
2. Place the D5 pump motor on top of the ULTITOP base part.
3. D5 NEXT only: Remove the controller unit from the pump
4. Slide the mounting ring onto the rear side of the pump motor and fasten the
ring by screwing it onto the ULTITOP base part.
5. D5 NEXT only: Re-attach the controller unit to the pump.
Integration into coolant loop
Integration into coolant loopIntegration into coolant loop
Integration into coolant loop
Connect the return line to the central connector of the ULTITOP D5 (engraved
“IN”) and connect the other line to the lateral connector. Use light force only when
screwing in fittings in order not to damage the threads in the plastic base part!
Replacement part information
Replacement part informationReplacement part information
Replacement part information
Gasket: 94767
Gelliehäuser Str. 1, 37130 Gleichen
c
o
m
p
u
t
e
r
a
q
u
a
