Consumer Hotline:

USA (800) 841-0884

INT’L (626) 254-9005

Monday - Friday 9 am - 5 pm, PST

www.arkon.com

Arcadia, CA 91006 USA

Designed in USA | Made in Taiwan & China

The Mobile Mounting Specialists™

Safety Precautions

Arkon is not responsible for any damages caused to your vehicle, your device, or yourself due to

the installation or use of this pedestal mount.

Do not install Arkon products over an air bag cover or within the air bag deployment zone. Arkon

Resources, Inc. assumes no responsibility of liability for injury or death as a result of car crashes

and / or air bag deployment.

Retighten the seat track bolt

Screw the mount bracket to the mount. Depending on your vehicle, you

may need to change the orientation of the bracket.

Attach the Floor / Console Bracket with screws.

Fig. A

Fig. B

Passenger Seat Bolt Mounting

Alternative Floor or Console Mounting

For permanent installation, connect the Floor / Console Mount Bracket to the ﬂoor

or console. This will require drilling into your vehicle’s interior surface.

For a simple mount that can be easily moved to another vehicle, install using the passenger seat track bolt.

Drilling into the dash, ﬂoor, or console will permanently damage the vehicle. Use

caution and consult a mobile install professional to avoid drilling into the gas tank,

electrical system or other highly sensitive vehicle components.

Do not place mount in or near an air bag deployment zone or

where it will obstruct view of the road.

Attach Holder and Mount Device

Mount Base Mount Base

Floor Bracket Floor Bracket

TAB188L22 | 22” Flexible Aluminum Car Seat Rail or Floor Mount

rev. 032417

GN088-L22-SBH

TAB001

With a socket wrench, loosen the passenger seat track bolt Insert the seat track bolt bracket

Adjustment Ring

Down

The Slim-Grip Universal Tablet Holder ﬁts all tablets with 8.9” - 18.4” screen size.

It includes 4 short, 2 medium, and 4 long support legs. Select a combination of 4

support legs in conjunction for use with the spring-loaded holder to achieve the

perfect ﬁt for your tablet.

Optional: Attach included metal conduit to console to minimize vibration.

Package Contents:

(1) TAB001 – Slim-Grip® Universal Tablet Holder

(1) GN088-L22-SBH – 22” Flexible Car Seat Rail or Floor Mount

Produktspecifikationer

Varumärke:	Arkon
Kategori:	ej kategoriserat
Modell:	TAB188L22
Inbyggda högtalare:	Nej
Korrekt användning:	Bil
Modell:	Passiv hållare
Kompatibilitet:	iPad Air 2, iPad 4, 3, 2, Galaxy Note
Produktens färg:	Svart
Strömkälla av typen:	Stöds inte
Mobilenhetens typ:	Surfplatta/UMPC
Typ av fäste för enheten:	Klämfäste
