Sida 1/13
User Manual
Atlona 4 Input HDMI Switcher
with Auto Switching
AT-HD4-V41 & AT-HD4-V42
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
AT-HD4-V41
AT-HD4-V42
2
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Table of Contents
1. Introduction ................................................................................................... 3
2. Package Contents ................................................................................................... 3
3. Features ................................................................................................... 3
4. Panel Descriptions
a. Front ................................................................................................... 4
b. Back ................................................................................................... 4
5. Infrared Remote Control ................................................................................................... 4
6. ARC ................................................................................................... 5
7. EDID ................................................................................................... 5
8. Step by Step guide ................................................................................................... 6
9. RS-232
a. Hyperterminal ................................................................................................... 7
a. Connection ................................................................................................... 7
b. Command ................................................................................................... 8
10. Installation Diagram ................................................................................................... 9
11. Specifications ................................................................................................... 10
12. Safety Information ................................................................................................... 11
13. Warranty ................................................................................................... 12-13
14. Registration ................................................................................................... 13
3
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
• HDMI 4 by 1 switcher or 4 by 2 switcher
• 5V DC power supply adaptor
• IR receiver module
• Remote control
• User Manual
• Four HDMI inputs
• Smart switching with auto-detect for inputs (activated through RS-232)
• Allows for a bi-directional HDMI Ethernet Channel pass through on output
• HDMI Audio Return Channel capable
• Supports HDCP
• Supports Deep color up to 36-bit color at 1080p 60Hz
• Supports Dolby TrueHD and DTS-HD Master Audio pass through ability when using an HDMI cable
• Digital audio de-embedding through the S/PDIF output for up to DTS 5.1 and Dolby Digital
IR Receiver
Introduction
Features
Package Content
The Atlona 4 input HDMI switchers are a great product for homes with multimedia systems and not enough
HDMI input options. The Atlona switchers support an Audio Return Channel and a 100Mbps Ethernet port
for HDMI Ethernet Channel (HEC), reducing the amount of wires necessary for compatible systems. The
Atlona switcher gives you a high digital performance connection, between four sources and a video display,
without signal loss.
