Sida 1/35
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Atlona 6 Input Switcher and
Scaler with HDBaseT and
Mirrored HDMI Output
Please check http://www.atlona.
com/AT-UHD-CLSO-612
for the most recent firmware
update or manual.
User Manual
AT-UHD-CLSO-612
2
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Revision B - Firmware 1.0.60 and OSD 1.1.0
Auto Switching Pg. 3, 15, 20, 27
VGA Preferred Timing Pg. 18, 27
HDVS Transmitters Pg. 20
Resolutions Pg. 10, 26
Video Adjustment Pg. 26
1. Introduction .......................................................................................... 3
2. Package Contents .......................................................................................... 3
3. Features .......................................................................................... 3
4. Panel Descriptions
a. Front Panel .......................................................................................... 4
b. Rear Panel .......................................................................................... 4
5. Wall/Rack mounts .......................................................................................... 5
6. Category cable .......................................................................................... 5
7. Analog Multi-Format Inputs .......................................................................................... 6
8. Audio Connections .......................................................................................... 7
9. Microphone .......................................................................................... 8
10. On Screen Display .......................................................................................... 9-11
11. TCP/IP and GUI .......................................................................................... 12-20
12. IR .......................................................................................... 21-23
13. RS-232
a. Connection .......................................................................................... 24
b. Set Up .......................................................................................... 24
c. Commands .......................................................................................... 25-27
d. IP Commands .......................................................................................... 28
e. Baud Rate .......................................................................................... 28-29
f. Control Diagram .......................................................................................... 29
14. Connection & Installation .......................................................................................... 30-31
15. Control Drivers .......................................................................................... 31
16. CLSO-612 Updating .......................................................................................... 31
17. Specifications .......................................................................................... 32-33
18. Safety .......................................................................................... 33
19. Warranty .......................................................................................... 34-35
20. Registration .......................................................................................... 35
Table of Contents
3
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Introduction
Easy to integrate, the CLSO-612 was designed for conference and classrooms with inputs at
lecterns, tables, and desks. Sources and displays can be up to 230 feet (70 meters) from the switcher
with HDBaseT inputs and outputs. Local HDMI and multifunction analog inputs work with any
source. Combined with great features such as: 4K up/down scaling, microphone ducking, and
audio control, this is the core component of your presentation AV system.
Package Contents
Features
• 1 x AT-UHD-CLSO-612
• 11 x Female Captive Screw Connector
6 pin: audio, 5 pin: IR, 3 pin: RS-232, 3 pin: MIC/Line
• 1 x 24V/2.7A DC power supply adaptor (AT-PW24V2.7A)
• 1 x Pair of dual purpose wall/rack mounts
• 1 x IR Remote Control
• 1 x User manual
• Accepts HDMI and HDBaseT inputs from up to 230 feet away
• Multifunctional VGA ports for RGBHV, component, S-Video, and composite signals
• Microphone (dynamic, phantom, and line) input with ducking
• HDBaseT output mirrored to HDMI output
• Auto switching - automated switching to last connected source without using a control system
• Balanced audio inputs for embedding audio
• Balanced (+4 dbu) analog audio output for de-embedding audio to amplifiers or audio systems
• Upscaling and downscaling to ensure compatibility with any display up to 4K resolution
• Control via RS-232, IR, TCP/IP, WebGUI, and multi-language On-Screen Display
• Master and sub volume control
• Adjust treble and bass on audio output to ensure the best speaker performance
• PoCC to HDBaseT inputs and outputs (no power required with compatible devices)
• HDCP Compliant
• Supports 3D pass through
