)NSTALLATION'UIDE
e
ProSafe 10 Gigabit Ethernet SFP+ Module AXM761
Install Your Optical Module
The 10 Gigabit small form-factor pluggable (SFP+) module provides a full-duplex 10G bps
each direction for Ethernet operation on NETGEAR managed switches.
The switch will automatically detect the AXM761, so you can simply plug it into an
available module slot.
The module can be inserted or removed while the switch is operational.
AXM761
Installing a AXM761 Module
Insert the module firmly into the slot that supports the SFP+ interface. Make sure the optical
cable you use is multi mode LC to LC duplex cable.
AXM761
Removing a AXM761 Module
Release the module latch by pulling down the handle bar across the module, and pull the
module out of the module slot.
Technical Specifications
StandardsIEEE 802.3ae 10GBase-SR
Wavelength850nm
Dimensions (HxWxD)0.46” x 0.53” x 2.19”
(11.9 mm x 13.7 mm x 55.7 mm)
Weight17.1g
Operating Temperature32 -158º F (0 - 70ºC)
Storage Temperature32 -185 ºF (0 - 85ºC)
Operative relative humidity85% @ (25ºC)
Operating Distance2 - 300 m for 50/125 um MMF
2 - 33 m for 62.5/125 um MMF
ConnectorsLC
Power Consumption<1.0w
MTBF4,986,536 hr (569 years)
Safety CertificationUL 1950 CSA 22.2 No. 950
Environmental Compliance-RoHS
AXM761_IG_10July09.fm Page 1 Friday, July 10, 2009 2:36 PM
