page 1
LC8
™
Eight Channel Line Output Converter with Auxiliary Input
For interfacing with factory installed audio systems
Greetings from the rainforests of the Pacic Northwest. We would
like to congratulate you on your purchase of the LC8i; a compact eight-
channel, high-performance, line-output converter. This unique product
will accept two, four, six or eight channels of speaker-level signal from a
factory-installed amplier or source unit and convert it to a high-quality,
low-noise pre-amp signal. It will also accept an auxiliary source so you
can integrate an iPod, Satellite Radio, or other source into your system.
In addition, the remote of the LC8i allows you to control the volume of
the auxiliary input and the Bass Output (Channel 4). Therefore, the LC8i
is an ideal OEM interface component. Whether this is your rst product
from the rainforest dwellers of AudioControl or you are already a rm
believer, you will denitely enjoy how great the LC8i can make your
performance system sound.
Now before you start salivating just thinking about the benets and all
of the nifty applications for your LC8i, take a few minutes to sit back,
have a cold beverage, and read through this manual. We always love to
hear from our customers, but have tried to answer all of your questions
in this manual so it contains lots of useful facts and information - - and
besides, we spent a lot of time writing it!
Key Features of The LC8i
Here are some of the cool features that your LC8i offers:
• Eight input and output channels
• Speaker-level inputs – can accept 400-watts per channel
• Auxiliary input for iPod, Satellite radio, or other source
•
Dash control for subwoofer level, auxiliary volume and source selection
• Compact size for easy installation
• Channel summing
• GTO™ - signal sensing inputs (selectable)
• Level matching controls
• 12 volt trigger output
• Recyclable cardboard box for easy storage
®
®
making good sound better
®
page 2
Features and Highlights
Speaker-Level Inputs
If you are like many people who like the look and features of their fac-
tory-installed source unit, but feel your system overall is lacking power
and bass, we have good news. The LC8i has high-impedance speaker-
level inputs that allow it to accept amplied signals (up to 400 watts per
channel) from most factory-installed source units (even Bose) and output
a high-quality pre-amp signal via standard RCA connectors. This will
allow you to add better-quality ampliers, processors and speakers while
keeping the convenience features of your factory-installed source unit.
Unlike inexpensive speaker-level and line-output converters available,
the LC8i offers high sound quality.
Auxiliary Source Input
A set of auxiliary RCA inputs connects the audio signal of an iPod or
other stereo source into the system through the LC8i. Tapping the in-
cluded LC8i remote knob will change from Main input to the Aux inputs
and tapping again will change the knob function from subwoofer level
control to auxiliary volume control
GTO™ Signal-Sensing Inputs
Most factory-installed source units lack the pre-amp features that make
it easy to upgrade with really good-sounding, performance after-market
products. One of those key features is a 12-volt trigger that will turn on
devices like the LC8i and your external ampliers. Therefore, we have
equipped your LC8i with our unique GTO™ (Great Turn On) Signal
sensing inputs. Once the GTO™ inputs of your LC8i detects a speaker-
level signal on its main inputs, it powers up. When the speaker-level
signal goes away, your LC8i will automatically turn-off. Optionally, you
can defeat the GTO™ with an internal jumper and use the +12-volt trig-
ger (Remote In) which is also provided.
12-Volt Trigger Output
Since you will be using an external amplier and processor in your
system, you will need the ability to “trigger” or turn-on these devices (a
romantic dinner and drinks won’t quite work here). Your LC8i has a high
current 12-volt output trigger (labeled Remote Out) that will provide a
12-volt output to trigger these remote devices, when the LC8i is powered
up. Please note that this output is not to be used as the main power for
these devices.
Summable Outputs
The LC8i has the capability to combine together multiple (2, 4, 6, or
8) input signals from the factory source unit into 2 channels. This is
page 3
particularly handy when using the LC8i with a factory system that has
multiple, actively crossed over signals being sent from an OEM source
unit or amplier(s). For example, in some vehicles there is an actively
crossed over tweeter, midrange, and woofer all in the front of the ve-
hicle. The LC8i lets you take all of those signals and sum them together
to get a high quality, full range, pre-amp signal without the use of any
additional cables or hardware.
AutoMode Inputs
Sometimes in life (and car audio) we need more outputs than inputs.
Therefore we have equipped your LC8i with an AutoMode input that
takes the channel 3 (rear) input signal and automatically feeds it to the
channel 4 outputs to drive a subwoofer amp and crossover, when there
is no signal present on the channel 4 inputs. This means your LC8i will
accept two input channels and give you four output channels. Or it can
accept four input channels and give you six output channels…or it can
accept six and give you eight!! It stops at eight by the way. Option-
ally, you can bypass the AutoMode, with an internal jumper, for certain
custom installations.
Level Matching Controls
Your LC8i has level controls for each pair of channels. These controls
allow you to adjust the signal level from your factory-installed amplier
or source unit to match up with your after-market amplier or processor.
The Auxiliary input also has a level-matching control to balance it with
the main inputs.
Remote Level/Source Control
A very unique dash mount control is provided with the LC8i. This is
a multi-function control, and serves to let the user choose between the
Main input (factory head unit) and the Auxiliary input (iPod, satellite
radio, or other source). The remote also serves to control the Channel
4 (subwoofer) output level. When you are using the Auxiliary input the
remote will independently control either the Aux Volume or the Channel
4 (subwoofer) output level.
Bulletproof Warranty
The most important feature of all. Every
AudioControl product is selessly designed
and manufactured by the occupants of our
factory located in the rainforest of the Pacic Northwest.
We take every effort to ensure that you will have many years
of enjoyment out of your LC8i. To ensure optimal performance we
highly recommend that you allow your authorized AudioControl dealer
