AXAMP-CH4
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 12/17/24 INSTAXAMP-CH4
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
• Multimeter
TABLE OF CONTENTS
Installation & Installation Options2 ........................
Adding Amp/Amps to a Factory System3 .............
Troubleshooting.....................................................4
APPLICATIONS
Visit for current application listAxxessInterfaces.com
INTERFACE COMPONENTS
• AXAMP-CH4 interface
• AXAMP-CH4 interface harness
• AXAMP-CH4 vehicle T-harness
• Bass knob
Fits Chrysler Amplifier Integration Interface
2007-2020
www.MetraOnline.com
MetraOnline.com may be used to assist
with dash assembly instructions. Simply
enter your Year, Make, Model vehicle
into the vehicle fit guide and look for the
Dash Kit Installation Instructions.
INTERFACE FEATURES
• Designed for both amplified and non-amplified models
• Provides 6 channels of 5-volt RMS audio
• Channels 5 & 6 are non-fading full range output
• Includes plug-n-play harnessing
• Simple behind the radio installation
• Dual colored LED feedback
• Input voltage 50 watts per channel
• Amp on turn-on output is rated at 250mA
• 2 channel S/PDIF out (Fronts)
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights, are
plugged in before reconnecting the battery or cycling
the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
