AXTC-TY1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 1/10/25 INSTAXTC-TY1
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape
• Wire cutter
• Zip ties
TABLE OF CONTENTS
Vehicle Applications2 ..............................................
Interface Connections............................................3
Programming4 .........................................................
Troubleshooting.....................................................5
Steering Wheel Control and Data Interface
Fits Lexus/Toyota 2002-2019
INTERFACE COMPONENTS
• AXTC-TY1 interface
• LD-SWCX-TY1 harness
• 3.5mm adapter
Product Info
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
Visit for more detailed information about the product and up-to-AxxessInterfaces.com
date vehicle specific applications.
www.MetraOnline.com
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter your
Year, Make, Model vehicle into the
Vehicle Fit Guide and look for the
Dash Kit Installation Instructions.
• Designed for amplified and non-amplified models
• Provides accessory power (12-volt 10-amp)
• Provides NAV outputs (illumination, parking brake, reverse,
speed sense)
• Retains audio controls on the steering wheel and allows dual
assigning of steering wheel control buttons
• Designed to be compatible with all major radio brands
• Auto detects vehicle type, radio connection, and preset controls
• Retains memory settings even after battery disconnection or
interface removal (non-volatile memory)
• Retains balance and fade (excludes amplified models)
• Retains the 3.5mm AUX-IN jack
• Micro “B” USB updatable
