INSTALLATION GUIDE

ENGLISH

AXIS T81B22 DC 30W Midspan

About this Document

This document includes instructions for

installing AXIS T81B22 on your network.

Previous experience of networking will be

beneficial when installing the product.

Electromagnetic Compatibility

(EMC)

This equipment has been designed and

tested to fulfill applicable standards for:

• Radio frequency emission when

installed according to the instructions

and used in its intended environment.

• Immunity to electrical and

electromagnetic phenomena when

installed according to the instructions

and used in its intended environment.

USA - This equipment has been tested

using a shielded network cable (STP) and

found to comply with the limits for a

Class B digital device, pursuant to part 15

of the FCC Rules. These limits are

designed to provide reasonable protection

against harmful interference in a

residential installation.

Canada - This Class B digital apparatus

complies with Canadian ICES-003.

Europe - This digital equipment

fulfills the requirements for RF emission

according to the Class B limit of EN

55022.

Australia - This digital equipment fulfills

the requirements for RF emission

according to the Class B limit of AS/NZS

CISPR 22.

Safety

This product complies to EN/IEC 60950-1,

2nd edition, Safety of Information

Technology Equipment.

The product’s data and data/power

Korea -

ࢇ



Еɼࢽࡈ%



ࢷ࢕ળࢶଢԻ۰

࣯Իɼࢽ߾۰یࡈଜЕʨࡶּࢶࡳԻଜֲֻҘ

ࠇ߾۰یࡈଟ

࢑ݡТЬ

Japan -

この装置は、クラス情報技術装置です。B

この装置は、家庭環境で使用することを目的として

いますが、この装置がラジオやテレビジョン受信機

に近接して使用されると、受信障害を引き起こすこ

とがあります。取扱説明書に従って正しい取り扱い

をして下さい。

interfaces are qualified as SELV (Safety

Extra-Low Voltage) circuits according to

IEC 60950. These interfaces can only be

connected to SELV interfaces on other

equipment.

WEEE Directive

The European Union has enacted a

Directive 2002/96/EC on Waste

Electrical and Electronic Equipment

(WEEE Directive). This directive is

applicable in the European Union member

states.

The WEEE marking on this product (see

right) or its documentation indicates that

the product must not be disposed of

together with household waste. To

prevent possible harm to human health

and/or the environment, the product

must be disposed of in an approved and

environmentally safe recycling process.

For further information on how to dispose

of this product correctly, contact the

product supplier, or the local authority

responsible for waste disposal in your

area. Business users should contact the

product supplier for information on how

to dispose of this product correctly. This

product should not be mixed with other

commercial waste.

Support

Should you require any technical

assistance, please contact your Axis

reseller. If your questions cannot be

answered immediately, your reseller will

forward your queries through the

appropriate channels to ensure a rapid

response. If you are connected to the

Internet, you can:

• download user documentation and

firmware updates

• find answers to resolved problems in

the FAQ database. Search by product,

category, or phrases

• report problems to Axis support by

logging in to your private support area at

www.axis.com/techsup.

Safeguards

Please read through this Installation Guide carefully before installing the

product. Keep the Installation Guide for further reference.

Caution!

• Store the Axis product in a dry and ventilated environment.

• Use only accessories that comply with technical specification of the

product. These can be provided by Axis or a third party.

• Do not attempt to repair the product by yourself, contact Axis or

your Axis reseller for service matters.

IMPORTANT!

• This product is intended for indoor use.

• DC Power Cable Set - the power cable must be rated for a minimum

current capacity of 3 amps (minimum 0.5mm2, AWG24).

• Use a limited power source, such as a mains adaptor, with rated

power output not exceeding either 100 W or 5 A.

• The DC power source must be near the AXIS Midspan and easily

accessible. You can disconnect DC power from the AXIS Midspan by

disconnecting the DC power cable from either the power source or

the AXIS Midspan.

• Voltage mismatch can cause equipment damage and may pose a fire

hazard. If voltage indicated on the label is different from power

source voltage, do not connect the Midspan to this power source.

• The Midspan "Data In" and "Data & Power Out" ports are shielded

RJ-45 data sockets. They cannot be used as Plain Old Telephone Ser-

vice (POTS) telephone sockets. Only RJ-45 data connectors may be

connected to these sockets.

Produktspecifikationer

Varumärke:	Axis
Kategori:	Nätverkskort/adapter
Modell:	High PoE Midspan
Vikt:	350 g
LED-indikatorer:	PoE, Power
Certifiering:	FCC Part 15, Class B with FTP cabling, EN 55022 Class B, EN 55024, VCCI, CB, UL/cUL per EN 60950-1, GS Mark per EN 60950-1, KCC, UL-AR
Kabelteknik:	10/100/1000 Mbps
Säkerhet:	FCC
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	2
Strömförbrukning (vanlig):	30 W
Strömförsörjning via Ethernet:	55 V
Produktstorlek (BxDxH):	51 x 88 x 166 mm
Temperatur vid drift:	-10 - 50 ° C
Temperaturintervall (förvaring):	-20 - 70 ° C
Intervall för relativ operativ luftfuktighet:	0 - 95 %
Efterlever industristandard:	IEEE 802.3af, IEEE 802.3at
AC-adapter, inspänning:	100 - 240 V
AC-adapter, frekvens:	50/60 hz
