Sida 1/44

ENGLISH DEUTSCH

ITALIANO

ESPAÑOL

INSTALLATION GUIDE

FRAN

AIS

AXIS T8121 High PoE Midspan 1-port

AXIS T8126 High PoE Splitter 12V

AXIS T8128 High PoE Splitter 24V

Safety information (for AXIS High PoE

Midspan only)

Installation and removal of the AXIS High PoE

Midspan must be carried out by qualified

personnel only.

• AC Power Cable Set:

• The power cable must have regulatory agency

approval for the specific country in which it is used

(for example, UL, CSA, VDE).

• The power cable must be a three-conductor type

(two current carrying conductors; one ground

conductor) terminated on one end by an IEC 60320

appliance coupler (for connection to the AXIS High

PoE Midspan), and on the other end by a plug

containing a ground (earthing) contact.

• The power cable must be rated for a minimum of

250Vac RMS operation, with a minimum rated

current capacity of 5 amps (or a minimum wire

gauge of 18 AWG (0.75mm

• Note: AXIS High PoE Midspans installed in Australia

require power cables with a minimum wire gauge of

16 AWG (1.0 mm

• The AC wall socket-outlet must be near the AXIS High

PoE Midspan and easily accessible. You can remove AC

power from the AXIS High PoE Midspan by

disconnecting the AC power cable from either the wall

socket-outlet or the AXIS High PoE Midspan appliance

coupler.

• The AXIS High PoE Midspan data and data/power

interfaces are qualified as SELV (Safety Extra-Low

Voltage) circuits according to IEC 60950. These

interfaces can only be connected to SELV interfaces on

other equipment.

WARNING!

• Read the installation instructions before connecting

the AXIS High PoE Midspan to its power source.

• Follow basic electricity safety measures whenever

connecting the AXIS High PoE Midspan to its power

source.

• A voltage mismatch can cause equipment damage

and may pose a fire hazard. If the voltage indicated

on the label is different from the power outlet

voltage, do not connect the AXIS High PoE Midspan

to this power outlet.

• This product relies on the building installation for

short-circuit (over current) protection. Ensure that a

fuse or circuit breaker no larger than 120 VAC, 3A.

U.S. (240 VAC, 1.5A international) is used on the

phase conductor.

• The AXIS High PoE Midspan "Data In" and "Data &

Power Out" ports are shielded RJ-45 data sockets.

They cannot be used as Plain Old Telephone Service

(POTS) telephone sockets. Only RJ-45 data

connectors may be connected to these sockets.

Notice:

In keeping with its policy to improve products, as new

technology, components, software, and firmware

become available, Axis reserves the right to change

specifications without prior notice.

Technical support (for AXIS High PoE Midspan

and Splitters)

Should you require technical assistance, please contact

your Axis reseller. If your questions cannot be answered

immediately, the reseller will forward your queries

through the appropriate channels to ensure rapid

response. If you are connected to the Internet, you can:

• Download user documentation

• Find answers to resolved problems in the FAQ database

• Search by product, category, or phrases

• Report problems to Axis support by logging in to your

private support area

• Visit Axis Support at www.axis.com/techsup/

EMC compliance

Category 5 foiled twisted-pair cables (FTP) must be used

to ensure compliance with the requirements of FCC Part

15, subpart B, Class B. The use of unshielded cables

(UTP) is in compliance with Class A requirements.

WEEE Directive

The European Union has enacted a Directive

2002/96/EC on Waste Electrical and Electronic

Equipment (WEEE Directive). This directive is

applicable in the European Union member

states.

The WEEE marking on this product (see right) or its

documentation indicates that the product must not be

disposed off together with household waste. To prevent

possible harm to human health and/or the environment,

the product must be disposed off in an approved and

environmentally safe recycling process. For further

information on how to dispose off this product correctly,

contact the product supplier, or the local authority

responsible for waste disposal in your area.

Business users should contact the product supplier for

information on how to dispose off this product correctly.

This product should not be mixed with other commercial

waste. For more information, visit

www.axis.com/techsup/

AXIS T8121 High PoE Midspan 1-port is identical to the

Microsemi PD-7001G (1-port High Power over Ethernet

Midspan).

AXIS T8126 High PoE Splitter 12V and AXIS T8128 High

PoE Splitter 24V are identical to the Microsemi

PD-AS-701/12 and PD-AS-701/24 (Power over Ethernet

Active Splitter).

High PoE Midspan and Splitters Installation Guide Page 3

ENGLISH

AXIS T8121

Package contents

Functions and features

The AXIS T8121 High PoE Midspan 1-port injects 48V DC power into data-carrying Ethernet cabling.

It maintains IEEE802.3af specification parameters while doubling the output power. These power

levels allowed a new range of Ethernet-based applications such as PTZ Cameras to use the High PoE

Midspan.

Preliminary steps

• Ensure AC power is applied to the AXIS T8121, using an operational AC cable with appropri-

ate ground connection.

• Ensure that output Ethernet cable is connected to the Data & Power Out port.

• Verify that a power ready Ethernet compatible device or splitter is connected.

Note:

Do not use a cross over cable between the AXIS T8121 output port and the powered device.

AXIS High PoE Midspan AXIS T8121 High PoE Midspan 1-port

Power cable (region specific) Europe

USA

Japan

Australia

Printed material Installation guide

Warranty document

Produktspecifikationer

Varumärke:	Axis
Kategori:	Nätverkskort/adapter
Modell:	T8121
LED-indikatorer:	Ja
Certifiering:	FCC Part 15, Class B / FTP\nEN 55022 Class B\nEN 55024, VCCI\nUL/cUL per EN 60950, GS Mark per EN 60950
Strömförsörjning via Ethernet:	55 V
Produktstorlek (BxDxH):	51.3 x 87.9 x 166 mm
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	0 - 90 %
Externa anslutningar:	RJ-45, EIA 568A & 568B\n
Efterlever industristandard:	IEEE 802.3at, IEEE 802.3af, RoHS
AC-adapter, inspänning:	100 - 240 V
AC-adapter, frekvens:	50/60 hz
