Sida 1/2
AXLOC-80SP AXLOC-80SP AXLOC-80SP
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 12/18/19 REV. 12/18/19 REV. 12/18/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
Wire Color & Function: The audio input wire colors are an EIA standard
for car stereo applications as follows.
INPUT HARNESS
White = Left front (+) input
White/Black = Left front (-) input
Gray = Right front (+) input
Gray/Black = Right front (-) input
Brown = Reference ground (-)
(Reference ground optional if noise is present)
Note:
Be sure that all audio input connections are polarized or in phase
with each other. That is, the positive output wires from the audio source
need to be connected to the corresponding positive input wires of the
AXLOC-80SP. The same goes for the negative audio wires. Failure to do
this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80SP for maximum performance: After completing
all of the necessary connections, turn the AXLOC-80SP adjustment pots
all of the way down by rotating them completely counter-clockwise.
Now, turn the stereo system on and adjust the main volume control on
the stereo to approximately 3/4 maximum volume. Select one of the
adjustment pots on the AXLOC-80SP and turn it slowly clockwise until
you notice audio distortion and then stop. Turn the remaining pot to the
same position as the previously adjusted pot. The audio set-up of the
AXLOC-80SP is now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA standard
for car stereo applications as follows.
INPUT HARNESS
White = Left front (+) input
White/Black = Left front (-) input
Gray = Right front (+) input
Gray/Black = Right front (-) input
Brown = Reference ground (-)
(Reference ground optional if noise is present)
Note:
Be sure that all audio input connections are polarized or in phase
with each other. That is, the positive output wires from the audio source
need to be connected to the corresponding positive input wires of the
AXLOC-80SP. The same goes for the negative audio wires. Failure to do
this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80SP for maximum performance: After completing
all of the necessary connections, turn the AXLOC-80SP adjustment pots
all of the way down by rotating them completely counter-clockwise.
Now, turn the stereo system on and adjust the main volume control on
the stereo to approximately 3/4 maximum volume. Select one of the
adjustment pots on the AXLOC-80SP and turn it slowly clockwise until
you notice audio distortion and then stop. Turn the remaining pot to the
same position as the previously adjusted pot. The audio set-up of the
AXLOC-80SP is now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA standard
for car stereo applications as follows.
INPUT HARNESS
White = Left front (+) input
White/Black = Left front (-) input
Gray = Right front (+) input
Gray/Black = Right front (-) input
Brown = Reference ground (-)
(Reference ground optional if noise is present)
Note:
Be sure that all audio input connections are polarized or in phase
with each other. That is, the positive output wires from the audio source
need to be connected to the corresponding positive input wires of the
AXLOC-80SP. The same goes for the negative audio wires. Failure to do
this will result in poor bass response and low quality audio.
Adjusting the AXLOC-80SP for maximum performance: After completing
all of the necessary connections, turn the AXLOC-80SP adjustment pots
all of the way down by rotating them completely counter-clockwise.
Now, turn the stereo system on and adjust the main volume control on
the stereo to approximately 3/4 maximum volume. Select one of the
adjustment pots on the AXLOC-80SP and turn it slowly clockwise until
you notice audio distortion and then stop. Turn the remaining pot to the
same position as the previously adjusted pot. The audio set-up of the
AXLOC-80SP is now complete and ready to be enjoyed.
The AXLOC-80SP is designed to convert speaker level audio to line level
audio. This allows for the installation of line level products such as amplifiers,
EQs and crossovers on systems that do not have RCA line level outputs.
Features:
80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion
Commonly Found On Other Brands of LOCs, 6:1 Step Down with
Variable Output, Detachable Input Plug, Gold Plated RCAs, Attractive &
Durable Enclosure
The AXLOC-80SP is designed to convert speaker level audio to line level
audio. This allows for the installation of line level products such as amplifiers,
EQs and crossovers on systems that do not have RCA line level outputs.
Features:
80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion
Commonly Found On Other Brands of LOCs, 6:1 Step Down with
Variable Output, Detachable Input Plug, Gold Plated RCAs, Attractive &
Durable Enclosure
The AXLOC-80SP is designed to convert speaker level audio to line level
audio. This allows for the installation of line level products such as amplifiers,
EQs and crossovers on systems that do not have RCA line level outputs.
Features:
80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion
Commonly Found On Other Brands of LOCs, 6:1 Step Down with
Variable Output, Detachable Input Plug, Gold Plated RCAs, Attractive &
Durable Enclosure
2 Channel, Adjustable Line Output Converter 2 Channel, Adjustable Line Output Converter 2 Channel, Adjustable Line Output Converter
