AXPIO-COM1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/3/25 INSTAXPIO-COM1

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Panel removal tool • Phillips screwdriver

• Torx screwdrivers • Tape

• Wire cutter • Zip ties

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Preparation .......................................................2

Kit Assembly ..........................................................2

Axxess Interface Installation

Interface Installation ........................................3

Dash Assembly ..................................................4

Radio Operation ............................................5-6

Odometer Type .................................................7

Radio Integration Package for Pioneer

®

Radios

Fits Jeep Compass 2017.5-2021

• Designed for non-amplified vehicles

•

Designed for Pioneer

®

DMH-W4600NEX/W4660NEX or DMH-WC5700NEX receivers

• Allows for the retention and adjustment of the factory personalization menu

through the Pioneer

®

radio

• Provides a visual view of HVAC and gauges on the Pioneer

®

screen (cannot be

adjusted via the screen)

(Features continued on next page

)

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets • C) Panel clips (7)

Not shown: LD-CH5-PIO, LD-CHRYHAZ2T,

Radio interface, PR04AVIC-PIO or PR04-PIORCA Harness,

External Speaker

AB

C

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Included with Kit

Antenna Adapter: Included with Kit

GPS Antenna Adapter: Included with Kit

Visit AxxessInterfaces.com

for up-to-date vehicle specific applications.

Product Info

IMPORTANT: TPMS will only display on the instrument cluster, not on the Pioneer

®

.

Visit MetraOnline.comfor more detailed information about the product and up-to-date

vehicle specific applications

INTERFACE FEATURES
