B-tech BT7382 Bruksanvisning
Sidor 16 Engelska Platt panelstöd
Läs bruksanvisningen för B-tech BT7382 gratis online eller ladda ner PDF:en. Bruksanvisningen har visats 31 gånger. Fråga om modellen? Ställ en fråga
B-TECH AUDIO VIDEO MOUNTS
www.btechavmounts.com
CONTENTS
INSTALLATION TOOLS REQUIRED
FEATURES
BT7382
FULL MOTION DESK MOUNT WITH SINGLE ARM
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Desk Mount
Crosshead
screwdriver
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................15
B-Tech Contact Details.....................................................................................................................16
PLEASE KEEP THIS FOR FUTURE REFERENCE
2.5mm Hex Key
(Supplied)
4mm Hex Key
(Supplied)
●Designed for screens up to 24" (61cm) / 9kg (20lbs)
●Fits screens with VESA mounting patterns:
75 x 75mm and 100 x 100mm
●Optional desk clamp and grommet included
●Maximum extension is 390mm (15.4”)
●Easy tilt adjustment +/-40° tilt
●Features two swivel points: 360° at pole and 180° at interface
●Simple installation with all mounting hardware included
Produktspecifikationer
| Varumärke: | B-tech |
| Kategori: | Platt panelstöd |
| Modell: | BT7382 |
| Kompatibilitet: | VESA 75 x 75mm / 100 x 100mm |
| Maximal skärmstorlek: | 24 " |
| Lutningsvinkel: | -40 - 40 ° |
| Maxvikt: | 9 kg |
| Produktens färg: | Svart |
| Monteringssätt: | Bord |
| Pivot vinkel: | Ja ° |
| Vridningsvinkel: | 180 ° |
| Antal vridpunkter: | 2 |
