PLEASE KEEP THIS PARTS LIST FOR FUTURE REFERENCE
PARTS LIST
17
18
19 20
21 22
1
DESIGNED FOR USE WITH AVIBALL. FOR BT880 STYLE BALL JOINT PRODUCTS
USE BT880-UN2 PROJECTOR MOUNT.
SUITABLE FOR M6, M5, M4 AND M3 MOUNTING HOLES. PLEASE USE THE
APPROPRIATE SCREWS AND WASHERS (PARTS 6 - 16) AS ILLUSTRATED.
THE LEGS (PARTS 4 + 5) CAN BE USED IN ANY NUMBER OR COMBINATION TO
SUIT YOUR PARTICULAR EQUIPMENT.
PARTS 19 - 21 ARE OPTIONAL AND CAN BE USED AS SPACERS AT THE
INSTALLERS DISCRETION. PARTS 22 CAN BE USED INSTEAD OF HAND WHEELS.
No
PART NAME
QTY
No
PART NAME QTY
1 CAROUSEL
1
13 M4 PLAIN WASHER 4
2 COVER PLATE HALF
2
14 M3 X 12 SCREW 4
3 HAND WHEEL
4
15 M3 SPRING WASHER 4
4 SHORT LEG
4
16
M3 PLAIN WASHER 4
5 LONG LEG
4
17
M8 SPRING WASHER 1
6 M6 X 12 SCREW
4
18
M8 X 23 SQUARE END
ALLEN SCREW
1
7
M6 SPRING WASHER
4 19 M6 PLAIN WASHER 8
8 M5 X 12 SCREW
4
20 M6*T6 SPACER 4
9 M5 SPRING WASHER
4
21 M6*T3 PLAIN WASHER 4
10 M5 PLAIN WASHER
4
22 M6 DOME NUT 4
11 M4 X 12 SCREW
4
23 5MM ALLEN KEY 1
12 M4 SPRING WASHER
4
24 M6 NUT 4
23
24
3
2
Cop
Cop
Cop
CopCopyr
yr
yr
yryrigh
igh
igh
ighight 2
t 2
t 2
t 2t 200
00
00
00007.
7.
7.
7.7. B-T
B-T
B-T
B-T B-Tec
ec
ec
ecech Int
h Int
h Int
h Inth Internat
ernat
ernat
ernaternati
i
i
iional
onal
onal
onalonal, i
, i
, i
, i, its
ts
ts
tsts dis
dis
dis
dis distri
tri
tri
tritribut
but
but
butbutors
ors
ors
orsors and
and
and
and and deal
deal
deal
deal dealers
ers
ers
ersers are
are
are
are are not
not
not
not not resp
resp
resp
resp respo
o
o
oonsi
nsi
nsi
nsinsible
ble
ble
bleble fo
fo
fo
fo for damag
r damag
r damag
r damagr damage
e
e
ee or in
or in
or in
or in or inj
j
j
jjury
ury
ury
uryury caus
caus
caus
caus caused
ed
ed
eded by
by
by
by by imp
imp
imp
imp impro
ro
ro
roroper
per
per
perper
ins
ins
ins
insinstal
tal
tal
taltallat
lat
lat
latlatio
io
io
ioion.
n.
n.
n.n.
www.btechavmounts.com
B-Tech International (Hong Kong) Ltd,
23rd Floor, Manulife Tower, North Point, HK.
Tel: (+852) 2556 7337 Fax: (+852) 2556 7321
Email: info@b-tech-int.com.hk
B-Tech PRO-AV bvba,
Brixtonlaan 32, Zaventem 1930,Brussels, Belgium.
Tel: +32 (0)2 720 92 71 Fax: +32 (0)2 725 42 15
Email: info@btechproav.com
B-Tech Audio Video Mounts,
Sparks, NV 89431, USA.
Tel: (1)800 975 5812 Fax: (1)800 592 2876
Email: info@btechavmounts.com
B-Tech International Ltd,
Long March, Daventry, Northants NN11 4NR, UK.
Tel: +44 (0)1327 300 787 Fax: +44 (0)1327 706 562
Email: info@b-tech-int.com
PAGE 1
