B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

TOOLS REQUIRED

FEATURES

BT8431

FLAT SCREEN WALL MOUNT WITH TILT

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Optional Accessories.........................................................................................................................10

Product Dimensions..........................................................................................................................11

B-Tech Contact Details.....................................................................................................................12

PLEASE KEEP THIS FOR FUTURE REFERENCE

● Designed for flat screens up to 50” (127cm) / 35kg (77lbs)

● Suitable for VESA & Non-VESA flat screens

● Mounts screen only 80mm (3.1”) from the wall

● Features Torsion Tilt mechanism for +/- 18° tilt

● Suitable for concrete / brick or stud walls up to 16” (40cm)

● Includes locking bar for secure installation

● Simple hook-on installation with all mounting

hardware included

13mm (1/2") spanner

or socket

Crosshead

screwdriver

Drill

Pencil

Stud finder

(optional)

Level

(optional)

COMMUNITY DESIGN NO. 001713280-0035

REG DESIGN NO: 3021714

PATENT APPLICATION NO: 0817023.5

10mm (7/16")

masonry bit or

6mm (1/4") wood bit

Produktspecifikationer

Varumärke:	B-tech
Kategori:	Platt panelstöd
Modell:	BT8431
Storlek:	21 "
Lutningsvinkel:	-15 - 15 °
Maxvikt:	35 kg
Produktens färg:	Silver
Monteringssätt:	Vägg
Vikt (imperial):	77 lbs
Kompatibla skärmstorlekar:	21/37 "
