www.bakerspride.com | p: 800-527-2100 265 Hobson St. Smithville, TN 37166
FEATURES AT A GLANCE
Bakers Pride
®
Y-BL series deck ovens are the best-selling
pizza ovens in the world. Each oven chamber features a
Cordierite brick-lined ceiling and Lightstone brament deck
with an 7.5" deck height. The Independently controlled
top and bottom heat dampers ensure perfectly balanced
results. Choose from two different deck areas and overall
oven widths (78" or 84") to suit your needs.
This series is constructed with heavy-duty angle iron
frame, which is fully welded to allow for double-stacking.
Oven exteriors are all heavy-duty stainless steel and
are fully insulated for cooler outer temperatures and
consistent interior temperatures.
Options are available to accommodate the conguration
of your kitchen, such as side-mounted controls and legs
with casters.
SERIES: Y-BL
• 120,000 total BTUH with natural
or LP gas
• 300–650°F (148–343°C)
temperature range
• Choose deck area: 60" x 36" (1524
x 914 mm) or 66" x 44" (1676 x
1118 mm)
• Choose overal width: 78" or 84"
• 2" (51 mm) thick Lightstone
brament, brick-lined decks
• 7.5" (191 mm) deck height
• Stackable
• Combination gas controls with
valve, regulator, and pilot safety
• Independently controlled top and
bottom heat dampers
• Front- or side-mounted gas
controls with valve, regulator, and
pilot safety
• Heavy-duty, slide-out flame
diverters
• All stainless steel exteriors,
aluminized steel interiors
• Spring-balanced, fully insulated
doors
• Left-side or rear 3/4" (19 mm)
NPT gas connection
SUPERDECK SERIES 7.5" DECK HEIGHT BRICK-LINED GAS PIZZA OVENS
• Draft flue for direct vent (not
available on CE units)
• Automatic oven starter (comes with
120v plug)
• Side-mounted controls (Specify
when ordering.)
• Deck brush and scraper (48" (1219
mm) long with wood handle)
• Stainless steel wood chip box
• Legs with casters
• Cordierite or steel decks
OPTIONS & ACCESSORIES
• Heavy-duty steel legs nished with
durable Bakertone
• Fully insulated throughout
• One-year limited warranty
2M-Z24901 REV C (07-23)
www.bakerspride.com | p: 800-527-2100 265 Hobson St. Smithville, TN 37166
EQUIPMENT DIMENSIONS
REQUIRED CLEARANCES
Non-Combustible Construction Combustible Construction
Left 0" (0 mm) 1" (25 mm)
Right 0" (0 mm) 3" (76 mm)
Back 2" (51 mm) 3" (76 mm)
GAS CONNECTIONS
3/4"
CE certication not available with LP gas
Each deck requires a separate gas connection
MECHANICAL SPECIFICATIONS
Model # Overall Dim••
(W x H x D)
Total
BTUH
***
kW
***
Deck
Height
Deck Size Decks Baking
Chambers
Thermostat
Range
Carton Dim
(W x H x D)
Cubic
Feet
Cubic
Meter
Ship Wt.•
Y-600BL 78" x 55.12" x 43"
(1981 x 1400 x 1092)
120,000 35.15 7.5"
(191)
60" x 36"
(1524 x 914)
1 1 300°-650°F
(149-343°C)
31" x 82" x 53"
(787 x 2083 x 1364)
76 2.4 1338
(607kg)
Y-602BL 78" x 66.25" x 43"
(1981 x 1683 x 1092)
240,000 70.3 7.5"
(191)
60" x 36"
(1524 x 914)
2 2 300°-650°F
(149-343°C)
* * * 2676
(1214kg)
Y-800BL 84" x 55.12" x 51"
(2134 x 1400 x 1295)
120,000 35.15 7.5"
(191)
66" x 44"
(1676 x 1118)
1 1 300°-650°F
(149-343°C)
31" x 86" x 60"
(787 x 2184 x 1524)
78 2.8 1542
(699kg)
Y-802BL 84" x 66.25" x 51"
(2134 x 1683 x 1295)
240,000 70.3 7.5"
(191)
66" x 44"
(1676 x 1118)
2 2 300°-650°F
(149-343°C)
* * * 3084
(1399kg)
• Each oven ships in separate carton as do the legs. Refer to the single unit for carton specs. Shipping weight shown includes all decks and legs.
••Height includes 30" (762 mm) legs on single units and 16" (406 mm) on stacked units.
***CE dertication not available in LP gas
SERIES: Y-BL
SUPERDECK SERIES 7.5" DECK HEIGHT BRICK-LINED GAS PIZZA OVENS
Freight Class: 77.5,
FOB Smithville 37166
Bakers Pride reserves the right to modify
specications or discontinue models without
incurring obligation. Dimensions nominal.
7.5”
(191 mm)
8.25”
(210 mm)
43.25”
(1099 mm)
30”
(762 mm)
3/4” NPT
GAS INLET
SIDE VIEW
See model depths in chart below
25.12”
(638 mm)
53.125”
(1349 mm)
55.12”
(1400 mm)
16”
(406mm)
66.25”
(1683 mm)
3/4” NPT
GAS INLET
7.5”
(191 mm)
SIDE VIEW
7.5”
(191 mm)
25.12”
(638 mm)
64.25”
(1632 mm)
8.25”
(210 mm)
54.37”
(1381 mm)
39.12”
(994 mm)
See model depth in chart below
29.25”
(743 mm)
3/4 NPT
GAS INLET
6.5”
(165 mm)
3/4 NPT
GAS INLET
11.5
(292 mm)
Flue Vent 6” (152 mm) dia
6.5” (165 mm)
3.5”
(89 mm)
TOP VIEW
See model widths in chart below
See model depths
in chart below
See deck areas
in chart below
54.75” (1391 mm)
2M-Z24901 REV C (07-23)
