Sida 1/3
30” TO 60”
IN 6” INCREMENTS
SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted By Date
WP29M SERIES
RANGE HOOD
Offers modern styling, high performance, and durable construction
to meet the needs of professional-quality residential cooktops.
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
WP29 Series
Hood
Best by Broan,
Best by Broan,
AEWP Series
Soffit Chimney
(Optional)
RMP Series
Backsplash
(Optional)
For domestic
cooking only.
HL0081
Model 415
(7” round adjustable elbow)
Model 427
(4
1
/
2
” x 18
1
/
2
”
to 10” Round,
6” high - lateral
Model 423
(4
1
/
2
” x 18
1
/
2
” to
10” Round - vertical
Model 424
(4
1
/
2
” x 18
1
/
2
” to
10” Round - horiz.
front/rear
Model 454
(4
1
/
2
” x 18
1
/
2
”
to 10” Round -
horiz. /right
Model 453
(4
1
/
2
” x 18
1
/
2
”
to 10” Round -
horiz. /left
WP29M
SERIES HOOD
(Canopy with
blower controls
& lighting.
Required for all
installations.)
OPTIONAL
DECORATIVE FLUE
AEWP SERIES
OPTIONAL
FLAT TOP COVER
ADPWP SERIES
NON-DUCT KIT FLUE
ANKWP SERIES
NOTE: We recommend the non-duct kit flue
ANKWP Series be installed with
Model P6 Blower/Rough-in kit, but
- WP29M SERIES RANGE HOOD SYSTEM -
INTERIOR BLOWERS
Model 437
(High capacity roof cap)
Model 441
(10’’ Round wall cap)
Model 634 or 644
(roof cap)
Model 647
(7” Round wall cap)
Model 407
(7” round duct—2 ft. sections)
Model 410
(10” round duct—2 ft. sections)
MODEL P6
BLOWER/ROUGH-IN KIT
(600 cfm interior blower &
rough-in plate)
MODEL P12
BLOWER/ROUGH-IN KIT
(1200 cfm interior blower
& rough-in plate)
Model 418
(10” round adjustable elbow)
the Model P12 can be used.
(Optional)
- WP29M SERIES RANGE HOOD SYSTEM -
IN-LINE AND EXTERIOR BLOWERS
In-line and exterior blower rough-in kit
(included with EB6, EB9, EB12, EB15,
ILB3, ILB6, ILB9 and ILB11 blowers.)
Model 418
10” Round
adjustable elbow
(optional)
Model ILB3 (280 cfm)
in-line blower
(includes one 8” to 10”
round transition)
Model EB6 (600 cfm)
or EB9(900 cfm)
exterior blower
Model EB12 (1200 cfm)
or EB15 (1500 cfm)
exterior blower
Model 441
(10” Round
wall cap)
Model 437
(High capacity roof cap)
Model 441
(10” Round wall cap)
Model 421
(10” Round vert.
in-line damper)
Recommended
for use with
exterior blowers
Model 410
(10” Round duct
—2ft. sections)
Model ILB6 (600 cfm)
in-line blower
(includes two 4½” x 18½”
to 10’’ round transitions)
Model ILB9 (800 cfm)
or ILB11 (1100 cfm)
in-line blower
(includes two 8” x 12” to
10’’ round transitions)
WP29M
SERIES HOOD
(Canopy with
blower controls
& lighting.
required for all
installations.)
OPTIONAL
DECORATIVE FLUE
AEWP SERIES
OPTIONAL
FLAT TOP COVER
ADPWP SERIES
(Can be installed in Vertical or Horizontal position.)
