Läs gratis den bruksanvisning för Blustream SC11HD-V2 (8 sidor) i kategorin Inte kategoriserad. Guiden har ansetts hjälpsam av 19 personer och har ett genomsnittsbetyg på 4.4 stjärnor baserat på 10 recensioner. Har du en fråga om Blustream SC11HD-V2 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/8
HDMI Output UpgradeL/R Out
Coaxial
Out
Link
Mode
3 2 1
1
0
0
DC 5V
L/R In HDMI Input EDID
Power
Link
3 2 1
1
0
0
SC11HD-V2
User Manual
SC11HD-V2 USER MANUAL
02 www.blustream.co.uk
Introduction 3
Features 3
Panel Descriptions 4
EDID Management 5
Mode Management 5
Application Diagram 6
Specifications 7
Package Contents 7
Maintenance 7
Contents
Surge protection device
recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. Use
of surge protection systems is highly
recommended in order to protect and
extend the life of your equipment.
Safety And
Performance Notice
Do not substitute or use any other
power supply other than the enclosed
unit, or a Blustream approved
replacement.
Do not disassemble either the
Transmitter or Receiver units for
any reason. Doing so will void the
manufacturer’s warranty.
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions carefully
before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
SC11HD-V2 USER MANUAL
03
contact support@blustream.co.uk / support@blustream.com.au
Our Blustream SC11HD-V2 is a HDMI 4K scaler, designed for installations with multiple
displays that support dierent maximum video resolutions. The SC11HD-V2 is ideal for
installations with muliple output resolution requirements.
The SC11HD-V2 supports down-scaling of 4K video to 1080P and supports HDCP 2.2 with
advanced EDID management. It also features either de-embedding or embedding audio
within the HDMI signal path.
Introduction
FEATURES:
• HDMI 4K video scaler
• Supports 4K UHD video input (3840 x 2160 @30Hz 4:4:4 with HDR) 3840 x 2160 @ 50/60Hz 4:2:0)
• HDMI output will downscale 4K@24/25/30Hz 4:4:4 to 1080P@24/25/30Hz, and 4K@24/25/30/50/60Hz 4:2:0 to 1080P@ 24/25/30 /50/60Hz
• Supports 10-bit HDR10
• Can be configured to work as either a HDMI audio de-embedder or audio embedder
• HDMI audio de-embedded to both analogue L/R audio and coaxial digital outputs concurrently (2CH PCM only)
• Embed analogue L/R 2CH audio input onto HDMI output
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Advanced EDID management
• HDCP 2.2 support
• CECandARCpassthrough
