Sida 1/1

Installation

1. Remove the tile from the ceiling and put the TBSF on top

of the ceiling tile, aligning the ends of the TBSF rails as

shown in the drawing at right.

2. Typically the ceiling speaker will be mounted in the center

of the ceiling tile. Care must be taken to ensure that the

TBSF rails will be flush with the tile sides and that the ring

portion will not interfere with the suspension grid.

3. Use the ring as a guide to cut a hole in the ceiling tile.

4. Sandwich the tile between the TBSF and the front bezel of

the speaker and secure the speaker clamps. Complete

speaker installation and connections as directed in the

speaker instruction manual.

The Bogen TBSF Tile Bridge Support is warranted to be free from defects in material and workmanship for two (2) years from the date of sale to the original purchaser.

Any part of the product covered by this warranty that, with normal installation and use, becomes defective (as confirmed by Bogen upon inspection) during the applicable

warranty period, will be repaired or replaced by Bogen, at Bogen’s option, provided the product is shipped insured and prepaid to: Bogen Factory Service Department,

50 Spring Street, Ramsey, NJ 07446, USA. Repaired or replacement product will be returned to you freight prepaid. This warranty does not extend to any of our products

that have been subjected to abuse, misuse, improper storage, neglect, accident, improper installation or have been modified or repaired or altered in any manner whatso-

ever, or where the serial number or date code has been removed or defaced.

THE FOREGOING LIMITED WARRANTY IS BOGEN’S SOLE AND EXCLUSIVE WARRANTY AND THE PURCHASER’S SOLE AND EXCLUSIVE

REMEDY. BOGEN MAKES

NO OTHER WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE ARE HEREBY DISCLAIMED AND EXCLUDED TO THE MAXIMUM EXTENT ALLOWABLE BY LAW. Bogen's liability arising out of the manu-

facture, sale or supplying of products or their use or disposition, whether based upon warranty, contract, tort or otherwise, shall be limited to the price of the product. IN NO

EVENT SHALL BOGEN BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS, LOSS

OF DATA OR LOSS OF USE DAMAGES) ARISING OUT OF THE MANUFACTURE, SALE OR SUPPLYING OF PRODUCTS, EVEN IF BOGEN HAS BEEN ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES OR LOSSES. Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above

limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from State to State.

Products that are out of warranty will also be repaired by the Bogen Factory Service Department – same address as above or call 201-934-8500. The parts and labor involved

in these repairs are warranted for 90 days when repaired by the Bogen Factory Service Department. All shipping charges in addition to parts and labor charges will be at the

owner's expense. All returns require a Return Authorization number. For most efficient warranty or repair service, please include a description of the failure.

12/2008

www.bogen.com

Specifications subject to change without notice.

54-2179-01B 1205

Limited Warranty; Exclusion of Certain Damages

Tile Bridge Support

Model TBSF

Description

This Bogen Tile Bridge Support (Model TBSF) is

designed to offer additional mounting support for

the Bogen High-Fidelity, Small-Footprint Speaker

(Model HFSF1) and Compact Ceiling Speaker
